ZYXEL 24-port Gigabit PoE L2 managed rack switch XGS2210-28HP 4X-SFP+ DSP0000042143

Zyxel features XGS2210-28HP
The Zyxel XGS2210-28HP is a Layer 2 managed switch designed for networks that need a high-performance Gigabit infrastructure, advanced management and power supply for devices via PoE. It has 24 Gigabit Ethernet ports, 4 SFP+ slots and 10G support, offering a configuration ready to connect numerous devices and provide high-speed links.
24 Gigabit Ethernet ports with connectivity 10G
Its 24 RJ-45 Gigabit Ethernet 10/100/1000 ports allow computers, access points, IP cameras and other network devices to be connected. They are complemented by 4 SFP+ slots and 10G support, expanding connection options in environments with greater bandwidth requirements.

24 RJ-45 Gigabit Ethernet ports 10/100/1000
4 slots for SFP+ modules
SUPPORT 10G
Switching capacity: 128 Gbit/s
Throughput: 95,2 Mpps

PoE power for up to 24 devices
Integrated Power over Ethernet allows power and data to be supplied through the Ethernet cable itself, simplifying compatible installations. The switch provides 24 PoE ports and a total power budget of 375 W, as well as compatibility with the IEEE 802.3af and IEEE 802.3at standards.

24 Power over Ethernet (PoE) ports
PoE budget E: 375 W
Compatibility with IEEE 802.3af and IEEE 802.3at
Maximum power consumption : 453 W

L2 management and web-based administration
As a Layer 2 managed switch, the Zyxel XGS2210-28HP provides functions for controlling and organising network traffic. It features web-based administration, QoS, VLAN, traffic classification and flow control, among other management tools.

Layer managed switch L2
Web-based management
Quality of Service (QoS) support
VLAN support
Private, protocol-based and port-based VLAN
Port mirroring
IP routing
Flow control support
Link aggregation
Storm control
Rate limiting
Spanning Tree Protocol
MAC address learning
ARP inspection
System event log

High capacity for managing network traffic
Its architecture provides a switching capacity of 128 Gbit/s and a throughput of 95.2 Mpps. The table supports up to 16,000 MAC addresses, and Jumbo Frame support of up to 9000 bytes facilitates the transfer of large volumes of data within compatible networks.

MAC address table: 16,000 entries
8 queues
Jumbo Frame support
Jumbo frames: 9000 bytes
Packet buffer : 1,5 MB

Security and access control features
The Zyxel XGS2210-28HP integrates an Access Control List (ACL) and various mechanisms to protect and control connections. It features MAC-based authentication, MAC address filtering, BPDU protection, and compatibility with 802.1x RADIUS, SNMP, SSH and SSH-2.

Access control list (ACL)
MAC-based authentication
MAC address filtering
802.1x RADIUS
SNMP
SSH and SSH-2
SSH/SSL support
BPDU protection and filtering
DHCP client
IGMP and multicast support

1U format for rack installation
With a 1U form factor and rack-mounting capability, this switch is ready to be integrated into organised network installations. Its black chassis is 440 mm wide and features power and status LED indicators for easy equipment monitoring.

Rack mounting
stackable
Form factor: 1U
COLOUR: BLACK
LED indicators: power and status
Dimensions: 440 x 330 x 44.5 mm
Weight: 5.06 kg
Noise level: 42.075 dB
Mean time between failures: 560,726 hours

Network standards compatibility
The device is compatible with numerous IEEE standards, facilitating its integration into network infrastructures with different technologies and connectivity requirements.

IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab and IEEE 802.1p
IEEE 802.1s, IEEE 802.1w and IEEE 802.1x
IEEE 802.3, IEEE 802.3ab and IEEE 802.3ad
IEEE 802.3af, IEEE 802.3at and IEEE 802.3az
IEEE 802.3u, IEEE 802.3x and IEEE 802.3z

Power supply and operating conditions
The Zyxel XGS2210-28HP supports an AC input of 100 to 240 V and 50-60 Hz. It can operate at temperatures from 0 to 50 °C and has a wide storage temperature range, making it suitable for installation in communications infrastructures.

Input voltage AC: 100-240 V
AC input frequency: 50-60 Hz
Operating temperature : 0-50 °C
Storage temperature : -40-70 °C
Operating relative humidity: 10-95%
Storage relative humidity: 10-90%
Heat dissipation: 1483.4 BTU/h

Other specifications
The switch includes MIB support and safety and electromagnetic compatibility certifications. The package includes the AC power cable and the items specified for rack mounting.

MIB support: RFC 1066, RFC 1213, RFC 1493, RFC 1643, RFC 1757, RFC 2011, RFC 2233, RFC 2358, RFC 2674, RFC 2819, RFC 2925, RFC 3621, RFC 4022, RFC 4113, RFC 4292 and RFC 4293
Safety: LVD, BSMI
Electromagnetic compatibility : FCC 15 (A), CE (A), BSMI
Certification: RoHS
Included cable: AC power
Mounting rack included
Package dimensions: 586 x 452 x 97 mm
Package weight: 6.4 kg
Harmonized System Code (SA): 85176990
Volume (m ³): 0.0099
