QNAP 4-bay NAS server without drives TS-453E-8G-CELERON J6412 8GB DSP0000015898

QNAP TS-453E-8G NAS 4XHDD-Bay 2x2.5Gb E 4xUSB
QNAP brand
MODEL TS-453E-8G
CPU - CPU: Intel Celeron J6412 quad-core, four-thread processor, with speeds of up to 2.6 GHz
- CPU architecture: 64-bit x86
- Graphics processors: Intel UHD Graphics
- Floating-point unit
- Encryption engine: (AES-NI)
- Hardware-accelerated transcoding
Memory - System memory: 8GB integrated memory (not expandable)
- Maximum memory : 8GB
Storage - Flash memory: 4GB (dual-boot operating system protection)
- Drive bays: 4 x 3.5" SATA drives at 6Gb/s
* The system is shipped without a hard drive
* To view the hard drive compatibility list, visit
- Drive compatibility:
SATA hard disk drives 3,5"
SATA solid-state drives 2,5"
- M.2 slot: 2 x PCIe M.2 2280 Gen slots 3 x 2
- Hot-swappable
- SSD cache acceleration support
File system
- Internal drives : EXT4
- External drives: EXT3, EXT4, NTFS, FAT32, HFS+, and exFAT (optional for ARM model)
Supported RAID types
- 8-bay (and above): JBOD, Single , RAID 0, 1, 5, 6, 10, 50, 60
- 6-bay: JBOD, Single , RAID 0, 1, 5, 6, 10, 50
- 4-bay: JBOD, Single , RAID 0, 1, 5, 6, 10
- 2-bay: JBOD, Single , RAID 0, 1
Storage management
- Maximum size of a single volume : 250 TB
- Maximum number of internal volumes : 128
- Maximum shared folder size : 250 TB
- Maximum number of shared folders : 512
Connections - 2 x 2.5 Gb E (2,5G/1G/100M/10M)
- 2 x USB 2.0
- 2 x USB 3.2 Gen 2 Type-A ports
- 2 x HDMI 1.4b
Features - Wake-on-LAN (WOL)
- Jumbo Frame
- File server:
File sharing on Windows, Mac and Linux / UNIX
Microsoft networking (CIFS / SMB)
Apple networking (AFP)
NFS version 3/4 services
- FTP server:
QuFTP
FTP, SFTP and TFTP protocols
FTP over SSL / TLS (explicit FTPS)
FX support
- Maximum FTP connections : 1024
- File Station (Web)
- Object storage
- Local user account : 4096
- Local group account : 512
- Domain user / group account : 200.000
Physical
- LED indicators: Power/Status, LAN, USB, hard drive 1-4
- Buttons: Power, reset, one-touch USB copy
- Operating temperature : 0 - 40 C
- Storage temperature : -20 - 70C
- Relative humidity: 5 ~ 95 % relative humidity, non-condensing, wet bulb : 27 ºC
- Power supply unit: Adapter 90 W, 100-240 V
- Power consumption: Hard drive standby mode : 28.974 W
- Power consumption: operating mode, typical : 35.79W
- Fan: 1 x 120 mm, 12 V DC
- System warning: Buzzer
- Kensington security slot
- Max. number of simultaneous connections (CIFS): with max. memory: 1500
Dimensions and weight
- Dimensions: 177 180 235 mm
- Weight (net): 3 kg
Volume (m ³): 0.0244
