OVISLINK Three-phase online tower uninterruptible power supply (UPS) PLATINUM-20K 20KVA 3/3 PLATINUM20
Notify me when available
Interested in this product? Drop us an email and we will let you know when it's available for order.
DeliveryUpdating delivery estimate…Order within the next — to receive it approximately Updating delivery estimate…
Updating delivery estimate…
Cuándo es más probable que llegue
Calculado con 0 entregas recientes
Fechas estimadas para España peninsular; se ajustarán con tu código postal y forma de entrega.
The date corresponds to the item with the longest delivery time
IVA intracomunitario
La exención intracomunitaria puede aplicarse a una entrega a otro Estado miembro si el NIF-IVA es válido y el destino cumple los requisitos. La comprobación por sí sola no determina el tratamiento fiscal.
Cómo se comprueba el IVA¿Eres profesional del sector?
Puedes solicitar una cuenta profesional e indicar los datos de tu actividad. La solicitud queda pendiente de revisión; puedes consultar su estado en tu cuenta.
Más información sobre cuentas profesionalesCanarias, Ceuta y Melilla sin IVA español
El tratamiento depende del destino de entrega y de la coherencia de la dirección. Pueden corresponder IGIC, IPSI, aranceles u otros cargos locales.
Más información sobre destinos e impuestosInput voltage 380V/400V/415V(line to line), 50/60Hz
Input connection 3Ph+N+PE
Power factor > ,0.99
Input voltage window +25%~-20%, full load
-20%~-40%, power derating between 100% to 70%
Frequency window 40-70HZ
Bypass input
Bypass voltage 380V/400V/415V
Bypass voltage window +15%--20%, full load
Frequency window ±5Hz
Battery
Battery voltage ±240VDC
Charger power 20%*Power
Charger voltage precision 1%
Output
Voltage precision ±0.5% (balance load),1% (unbalance load)
Output voltage transient 5%(0~100% load step)
Voltage THD(Total Harmonic Distortion) THD<,1%(linear load),THD<,5%(nonlinear
load)
Power factor 0.8
Frequency tracking range 50/60Hz±3Hz, adjustable
Frequency precision (free running) ±0.02%
Phase tolerance 120°±0.5° (balance and unalance load)
Voltage unbalance degree (100% unbalance load) ±1%
Frequency tracking speed 0.5Hz/s to 5Hz/s, adjustable
Crest factor 3:1
Overload capability 102% long time operation
110%, transfer to bypass after 1hour
125%, transfer to bypass after 10 minutes
150%, transfer to bypass after 1 minute
>150%, transfer to bypass after 200ms
Bypass overload capability 125%, long time operation
125%<, load <,130%, last for more than 1 hour
130%
>1000%, last for more than 100ms
System
System efficiency Normal mode: 95%
ECO mode: 99%
Battery mode efficiency 95%
Battery configuration 12V, 40PCS (36~44pcs acceptable)
Display LCD+LED, keyboard
EMI IEC62040-2
EMS IEC61000-4-2(ESD)
IEC61000-4-3(RS)
IEC61000-4-4 (EFT)
IEC61000-4-5 (Surge)
Insulation resistance > ,2M (500VDC)
Dielectric strengh (input,output to PE)2820Vdc, leakage current lower than 3.5mA,
no flashover in 1 minute
Surge protection Comply with IEC60664-1 class IV, endure surge of 1.2/50us +
8/20us higher than 6KV/3KA
IP rating IP20
Interface (Communication Ports ) RS232,RS485,Dry contacts,SNMP
card,EPO,Generator interface
Installation/connection: top or bottom cable connection
Operating temperature 0-40
Relative humidity 0-90% (non-comdensing)
Noise (dB) <55 dB
Volume (m ³): 0.3414
- Brand
- OVISLINK
- Reference
- PLATINUM20
- EAN-13
- 8604212074686
- Weight
- 100 kg
