OVISLINK Modular three-phase online uninterruptible power supply (UPS) without batteries KRYPTON-60KVA KRYPTONC60
DeliveryUpdating delivery estimate…Order within the next — to receive it approximately Updating delivery estimate…
Updating delivery estimate…
Cuándo es más probable que llegue
Calculado con 0 entregas recientes
Fechas estimadas para España peninsular; se ajustarán con tu código postal y forma de entrega.
The date corresponds to the item with the longest delivery time
IVA intracomunitario
La exención intracomunitaria puede aplicarse a una entrega a otro Estado miembro si el NIF-IVA es válido y el destino cumple los requisitos. La comprobación por sí sola no determina el tratamiento fiscal.
Cómo se comprueba el IVA¿Eres profesional del sector?
Puedes solicitar una cuenta profesional e indicar los datos de tu actividad. La solicitud queda pendiente de revisión; puedes consultar su estado en tu cuenta.
Más información sobre cuentas profesionalesCanarias, Ceuta y Melilla sin IVA español
El tratamiento depende del destino de entrega y de la coherencia de la dirección. Pueden corresponder IGIC, IPSI, aranceles u otros cargos locales.
Más información sobre destinos e impuestosMain Input
Input voltage "380V/400V/415V(line to line)220V/230V /240V(line to neutral)"
Input frequency 50/60Hz
Power factor > ,0.99
Input voltage window -40%~+25%
Frequency window 40-70HZ
Battery
Battery voltage ±240VDC
Charger power 20%*Power
Charger voltage precision 1%
BYPASS
Bypass voltage "380V/400V/415V, three phase220V/230V/240V, one phase"
Bypass voltage window -20%-+15%, full load, settable
Bypass overload capability 125%, long time operation
125%<, load <,130%, last for more than 1 hour
130%
>1000%, last for more than 100ms
Output
Output voltage "380V/400V/415V, three phase220V/230V/240V, one phase"
Voltage precision ±0.5% (balance load),±1% (unbalance load)
Voltage THD(Total Harmonic Distortion) THD<1%(linear load),THD<5%(nonlinear load)
Power factor 0.8
Phase tolerance 120°±0.5° (balance and unalance load)
Crest factor 3:1
Overload capability 105%,long time operation
110%, transfer to bypass after 1hour
125%, transfer to bypass after 10 minutes
150%, transfer to bypass after 1 minute
>150%, transfer to bypass after 200ms
System
System efficiency Normal mode: 95%
ECO mode: 99%
Battery mode efficiency 95%
LCD+LED display, touchscreen and keyboard
IP rating IP20
Interface (communication ports): RS232, RS485, dry contacts, SNMP card, EPO, generator
Interface
Installation/connection: top or bottom cable connection
Operating temperature 0-40
Storage Temperature -25~70
Relative humidity 0–95% (non-condensing)
Noise (dB) <55 dB
Weight (KG) 6-module cabinet RM060/10, RM090/15, RM120/20
150KG
10-module cabinet RM100/10, RM150/15, RM200/20
180KG
PM10 10KVA: 20KG
PM15 15KVA: 21KG
PM20 20KVA: 22KG
Dimensions (W*D*H) (mm) 6-module cabinet 600*900*1600
10-module cabinet 600*900*2000
Module 400*600*133 (10KVA/15KVA/20KVA)
Volume (m ³): 1.5975
- Brand
- OVISLINK
- Reference
- KRYPTONC60
- EAN-13
- 6034212392664
- Weight
- 356 kg
