NILOX Line-interactive UPS with AVR voltage regulator PREMIUM-LINE 1500VA DSP0000006995

DESCRIPTION
The 1,500 VA Line Interactive UPS is perfect for protecting computers and peripherals from
power outages, filtering disturbances from the mains: these are very
frequent and very harmful to electronic equipment, causing faults
over time. Avoiding these problems means increasing the average lifespan of all
connected devices and being able to save your work with complete peace of mind in the event of
a power cut. Line Interactive technology, thanks to the AVR system
(Automatic Voltage Regulator), enables intelligent voltage and
battery management, extending its lifespan: this is because in a UPS without AVR, when the voltage
if the input voltage falls outside the preset threshold, the battery kicks in to
supply power to the connected loads. AVR, on the other hand, is responsible for
returning the voltage to optimal parameters even when constant fluctuations occur
without immediately resorting to the battery, which is activated only when the
fluctuations are extreme and cannot be corrected. The 1,500 VA line-interactive unit
The 1,500 VA line-interactive unit NXGCLI15001X9V2 is equipped with a 9Ah battery, code
single replacement battery code 17NXBA9A00001T - 17NXBA9A00001
Technical specifications

WEIGHT AND DIMENSIONS
HEIGHT
324 mm
WIDTH
220 mm
DEPTH
140 mm
Ports and Interfaces
Number of AC outputs
2 AC outputs
Battery
Hot-swappable battery
YES
Battery capacity
9 Ah
Number of supported batteries
1
Number of battery cells
1
Battery technology
LITHIUM
Typical backup time at full load
5 min
Typical backup time at half load
10 min
Battery recharge time
8 h
Battery voltage
12 V

Design
Product color
BLACK
Form factor
Tower
Housing material
PLASTIC
Characteristic
Automatic voltage regulation (AVR)
YES
Audible alarm(s)
YES
Output power capacity (VA)
1.5 kVA
Waveform
Pseudo sine
Input frequency
50/60 Hz
Output frequency
50/60 Hz
Noise level
40 dB
Output power
1050 W
RESPONSE TIME
2 ms
UPS topology
Line interactive
Operating input voltage (min)
220 V
Operating input voltage (max)
230 V
Volume (m ³): 0.0102
