INTEL Server processor XEON-BRONZE-3508U LGA4677 BOX DSP0000043142

Intel Xeon Bronze 3508U 2.1 GHz Processor Features 22,5 MB
The Intel Xeon Bronze 3508U is a processor for servers and enterprise environments, belonging to the 5th generation of Intel Xeon Scalable. Equipped with 8 cores, 8 threads and a base frequency of 2.1 GHz, it offers processing capacity for professional infrastructures that require stability, memory management and advanced security features. Its compatibility with ECC memory, virtualization and Intel acceleration technologies makes it an option designed for single-processor server systems.
8-core processing with Intel Turbo Boost technology
The Intel Xeon Bronze 3508U integrates 8 physical cores and 8 execution threads, with a base frequency of 2.1 GHz and a turbo frequency of up to 2.2 GHz. Its 22.5 MB cache helps provide access to data frequently used by the processor, while its 64-bit architecture allows it to run compatible enterprise applications.

Family: Intel Xeon Bronze.
Model: Intel Xeon Bronze 3508U.
Generation: 5th generation Intel Xeon Scalable.
Cores and threads: 8 cores and 8 threads.
Base frequency: 2.1 GHz.
Turbo frequency: up to 2.2 GHz.
Intel Turbo Boost technology: version 2.0.
Air Filter : 22,5 MB.
Architecture: 64-bit, with Intel technology 64.
Code name: Sapphire Rapids.

Eight-channel memory and ECC compatibility
Thanks to its eight-channel memory controller, this processor is designed to manage large amounts of memory in servers and enterprise platforms. It supports a maximum capacity of 4 TB and includes ECC memory compatibility, which can detect and correct certain memory errors to improve system reliability.

Memory channels: 8.
Maximum memory capacity : 4 TB.
ECC compatibility: sí.

PCI Express connectivity and server platform
The FCLGA4677 socket allows the Intel Xeon Bronze 3508U to be installed in compatible motherboards. Its support for 80 PCI Express 4.0 lanes facilitates connectivity with compatible storage devices, controllers and expansion cards. In addition, its 1S scalability is designed for single-processor configurations.

Socket: FCLGA4677.
PCI Express version: 4.0.
Maximum number of PCI Express lanes: 80.
Scalability: 1S (one processor).
Segment: servidor.
Terms of use: Server/Enterprise.
Integrated options: disponibles.

Advanced security and data protection features
The processor incorporates a set of Intel technologies designed to secure the system and protect information. These include Intel Total Memory Encryption, Intel SGX and Intel Trusted Execution Technology, designed to strengthen the protection of memory, execution environments and system processes.

Intel Total Memory Encryption (TME): supported.
Intel Total Memory Encryption - Multi-Key: supported.
Intel Software Guard Extensions (SGX): supported, with a maximum enclave size of 64 GB.
Intel Control-flow Enforcement Technology (CET): supported.
Intel Trusted Execution Technology: compatible.
Intel Platform Firmware Resilience: compatible.
Intel AES-NI: supported.
Intel OS Guard: compatible.
Intel Boot Guard: compatible.
Execute Disable Bit: compatible.

Virtualization and workload acceleration
This model features Intel VT-x and VT-d virtualization technologies, which enable the management of compatible virtualized environments and optimize access to hardware resources. It also incorporates instruction extensions and acceleration features such as Intel Deep Learning Boost, Intel QuickAssist and Intel Data Streaming Accelerator, designed for specific computing, data processing and enterprise operations.

Intel Virtualization Technology (VT-x): supported.
Intel VT-d: directed I/O virtualization.
Intel VT-x with Extended Page Tables (EPT): supported.
Mode-Based Execution Control (MBE): supported.
Intel Deep Learning Boost (DL Boost): supported.
Intel Crypto Acceleration: compatible.
Intel QuickAssist: software acceleration supported.
Intel Data Streaming Accelerator (DSA): 1 default device.
Intel Transactional Synchronization Extensions: compatible.
Intel Resource Director Technology (RDT): supported.
Intel Volume Management Device (VMD): compatible.
Intel Speed Shift: compatible.
Supported instructions: AMX, AVX, AVX 2.0, AVX-512 and SSE4.2.
UNITS AVX-512 FMA: 1.

Thermal consumption and physical characteristics
The Intel Xeon Bronze 3508U has a thermal design power of 125 W, so it requires a cooling solution and platform compatible with its specifications. It is intended for server systems and does not include integrated graphics, so video output requirements must be met by the platform hardware.

Thermal design power (TDP): 125 W.
Maximum DTS : 98 °C.
Tcase temperature : 83 °C.
Integrated graphics adapter: no.
Discrete graphics adapter included: no.
PRESENTATION: caja.

Other technical specifications
The processor has technical identifiers and classification data that facilitate its lookup in product documentation, compatibility references and enterprise inventory management.

MAKER: Intel.
Intel ARK ID: 236639.
Stepping: U1.
Package carrier: E1B.
Release date: fourth quarter of 2023 (Q423).
Product status: Launched.
Maintenance status: Baseline Servicing.
Export control classification (ECCN): 5A992C.
CCATS: 740.17B1.
Harmonized System Code (SA): 8542310050.
Volume (m ³): 0.0015
