AMD Desktop processor RYZEN 7 7700X3D AM5 BOX DSP0000041979

AMD Ryzen processor features 7 7700X3D AM5
The AMD Ryzen 7 7700X3D is a high-performance desktop processor designed for users seeking powerful performance in gaming, content creation and demanding tasks. Based on the AMD Zen 4 architecture and compatible with the AM5 socket, it combines 8 cores, 16 threads and a large cache to deliver smooth performance in modern applications. It also features integrated AMD Radeon graphics and compatibility with the latest memory and connectivity technologies.
Zen 4 architecture for high performance
Thanks to its Zen 4 architecture, this processor offers an excellent balance between power and efficiency. Its 8 cores and 16 threads, together with Precision Boost 2 and Precision Boost Overdrive technologies, automatically adjust performance to meet the most demanding workloads.

8 cores and 16 threads.
AMD Zen 4 architecture (Raphael AM5).
TSMC 5 nm (CCD) and 6 nm (IOD) manufacturing process.

Large cache capacity and operating frequencies
Its large cache and high frequencies reduce response times and improve performance in both video games and professional applications.

Base frequency of 4 GHz.
Maximum frequency of up to 4.5 GHz.
96 MB L3 cache, 8 MB L2 cache and 512 KB cache L1.

Compatible with DDR5 memory and platform AM5
The Ryzen 7 7700X3D is ready for the latest platforms thanks to its compatibility with DDR5 memory and a wide range of AM5 chipsets, providing a solid foundation for next-generation systems.

Up to 128 GB of memory DDR5 UDIMM.
ECC memory support (depending on the motherboard).
Compatible with A620, B650, B650E, X670, X670E, X870, X870E, B840 and chipsets B850.

Advanced connectivity and PCIe support 5.0
This processor supports the latest connection technologies, making it easy to install high-performance NVMe drives and the latest-generation expansion cards.

PCI Express interface 5.0.
28 total PCIe lanes (24 usable).
Compatible with NVMe Boot, RAID 0, RAID 1 and RAID 10.

Integrated AMD Radeon graphics
The processor features an integrated AMD Radeon Graphics GPU, sufficient for productivity and multimedia tasks and basic configurations without the need to install a dedicated graphics card.

Integrated AMD Radeon Graphics.
2 graphics cores.
Graphics frequency of up to 2,200 MHz.

Security and tools for advanced users
AMD integrates a comprehensive set of security, virtualization and management features, as well as compatibility with AMD Ryzen Master to make system optimization and tuning easier.

AMD Secure Processor and Secure Boot.
Compatible with AMD Ryzen Master.
AMD EXPO for memory overclocking and support for AMD-V virtualization.

Other specifications

Socket: AM5.
Form factor: desktop processor (Box version).
TDP of 120 W.
Maximum temperature (Tjma x): 89 °C.
Compatible with Windows 11 64-bit, Windows 10 64-bit, Ubuntu x86 64-bit and RHEL x86 64-bit.
x86-64 instruction set with support for AES, AVX, AVX2, AVX512, FMA3, SSE and other extensions.
4 USB 3.2 Gen2 (10 Gbps) ports and 1 USB 2.0 (480 Mbps) port supported by the platform.
Compatible with USB Type-C DisplayPort Alternate Mode.
AMD recommends using liquid cooling for optimal performance.
Heatsink/fan not included (Box version without fan).
Volume (m ³): 0.0015
