INTEL Unlocked 24-core processor for LGA 1851 socket, without heatsink CORE-ULTRA-7 270K PLUS TRAY DSP0000041746

Intel Core Ultra 7 270K Plus Processor Features
ARTICLE BULK
HEATSINK NOT INCLUDED
The Intel Core Ultra 7 270K Plus is a desktop processor from the Intel Core Ultra Series 2 generation, designed for high-performance systems, workstations and professional platforms. Its hybrid architecture combines 8 performance cores and 16 efficiency cores, for a total of 24 cores and 24 threads. It also features Intel Graphics and an Intel AI Boost NPU to accelerate compatible artificial intelligence workloads.
24-core hybrid architecture
The combination of Performance-cores and Efficient-cores enables workloads to be distributed efficiently. Performance cores handle the most demanding tasks, while efficiency cores manage background processes and parallel workloads, delivering a balanced response in professional applications, content creation and multitasking.

8 Performance-cores

16 Efficient-cores
24 cores and 24 processing threads
Maximum processor turbo frequency: 5.5 GHz
Performance-core base frequency: 3.7 GHz
Performance-core boost frequency: 5.4 GHz
Efficient-core base frequency: 3.2 GHz
Efficient-core boost frequency: 4.7 GHz
Low Power Efficient-cores : 0
64-bit operating mode

Cache memory and power for demanding workloads
The processor features 36 MB of Intel Smart Cache and 40,960 KB of L2 cache, providing fast access to the most frequently used data. Its 125 W base power and 250 W maximum turbo power are designed for high-performance configurations with adequate cooling.

Processor cache : 36 MB

Cache type: Intel Smart Cache
Air Filter L2: 40.960 KB
Processor base power : 125 W
Maximum turbo power : 250 W
Thermal solution specification : PCG 2020A
Maximum supported temperature : 105 °C

Intel AI Boost for artificial intelligence applications
The Intel AI Boost neural processing unit enables dedicated execution of artificial intelligence workloads, reducing reliance on the CPU and GPU for supported tasks. The processor delivers total performance of up to 36 TOPs and is compatible with various AI work environments used in Windows and professional applications.

Neural processing unit: Intel AI Boost

NPU core performance: up to 13 TOPs
Total processor performance: up to 36 TOPs
GPU performance: up to 8 TOPs
Sparsity support: Yes
Windows Studio Effects support: Yes
NPU-compatible environments: DirectML, OpenVINO, Windows ML, ONNX RT and WebNN
CPU-compatible environments: DirectML, OpenVINO, Windows ML, ONNX RT and WebNN
GPU-compatible environments: DirectML, OpenVINO, Windows ML, ONNX RT and WebGPU

Memory support up to 256 GB
The Intel Core Ultra 7 270K Plus supports a dual-channel memory configuration with up to 256 GB of capacity. It also supports ECC memory, a feature that is particularly useful in workstations and systems where data integrity is a priority.

Maximum supported internal memory : 256 GB

Memory channels: Dual channel
ECC support: yes

Integrated Intel graphics
The integrated Intel Graphics allows the system to be used without having to install a dedicated graphics card. It features 4 Xe cores, reaches a dynamic frequency of up to 2,000 MHz and supports up to four displays, as well as hardware video encoding and decoding.

Built-in graphics adapter: Yes

Graphics model: Intel Graphics
Xe cores : 4
Base graphics frequency: 300 MHz
Maximum dynamic graphics frequency: 2,000 MHz
Maximum number of displays : 4
Direct support X 12.0
Open compatibility GL 4.5
Open compatibility CL 3.0
Supported graphics outputs: eDP 1.4b, DisplayPort 2.1 UHBR20 and HDMI 2.1 FRL
Maximum resolution via DisplayPort: 7,680 x 4,320 pixels at 60 Hz
Maximum refresh rate via eDP: 120 Hz
Maximum refresh rate via HDMI: 60 Hz
Supported hardware codecs: H.264 and H.265 HEVC
AV1 encoding and decoding: yes
Intel Quick Sync Video: yes
Discrete graphics adapter: not included
Integrated graphics adapter ID: 0x7D67

PCI Express 4.0 and connectivity 5.0
Support for PCI Express 4.0 and PCI Express 5.0 makes it easy to build modern platforms with graphics cards, storage drives and other high-speed devices. The processor supports up to 24 PCI Express lanes and uses a DMI 4.0 interface.

Supported PCI Express versions: 4.0 and 5.0

Maximum number of PCI Express lanes: 24
Maximum number of lanes DMI: 8
DMI revision: 4.0
Scalability: 1S
Socket: FCLGA1851

Intel technologies for performance and security
This processor integrates a broad range of performance, virtualization, management and data protection technologies. These features make it suitable for advanced computers as well as compatible workstations and enterprise platforms.

Intel Turbo Boost 2.0

Intel Turbo Boost Max Technology 3.0 with a frequency of up to 5.5 GHz
Intel Thread Director
Intel Speed Shift
Enhanced Intel SpeedStep Technology
Intel Deep Learning Boost on CPU and GPU
Intel AES New Instructions
Intel Secure Key
Intel OS Guard
Intel Boot Guard
Intel Control-Flow Enforcement Technology
Intel Threat Detection Technology
Intel Trusted Execution Technology
Intel 64
Execute Disable Bit
MBE mode-based execution control
Intel Total Memory Encryption - Multi-Key
Intel Hyper-Threading: no

Virtualization and enterprise management
Support for Intel vPro, Intel AMT and various virtualization technologies enables the processor to be deployed in professional systems requiring remote management, enhanced protection and execution of virtualized environments.

Intel VT-x virtualization technology

Intel VT-x with Extended Page Tables EPT
Intel VT-d virtualization technology for directed I/O
Intel Virtualization Technology with Redirect Protection VT-rp
Intel Active Management Technology
Intel Standard Manageability
Intel Volume Management Device
Intel One-Click Recovery
Intel Remote Platform Erase
Intel vPro Enterprise eligibility
Intel vPro Essentials eligibility
Intel vPro platform eligibility
Intel Stable Image Platform Program
Intel Thunderbolt 4 support

Tray format for integrators
The processor is supplied in tray format, a presentation primarily intended for integrators, system builders and equipment manufacturers. This type of packaging may not include a heatsink or the usual accessories supplied with a retail boxed version.

Packaging type: tray

Manufacturer: Intel
Family: Intel Core Ultra 7
Model: 270K Plus
Generation: Intel Core Ultra Series 2
Code name: Arrow Lake
Market segment: desktop
Usage conditions: workstation, PC, client and tablet

Other specifications
The Intel Core Ultra 7 270K Plus includes additional features designed to improve stability, thermal monitoring and compatibility with current applications and systems.

Supported instruction sets: AVX 2.0, SSE4.1 and SSE4.2

Idle states: yes
Intel Thermal Monitoring Technology: yes
Embedded options available: no
Processor size: 45 x 37,5 mm
Indicated release date: Q126
Status: launched
Intel Processor ARK ID: 245692
Volume (m ³): 0.0015
