BROTHER Direct thermal label printer TD-4520DN 300PPP-USB-ETHERNET MGS0000001259

Features of the Brother label and receipt printer TD-4520DN
The Brother TD-4520DN is a professional direct thermal label and receipt printer designed for office, retail, logistics and healthcare environments that require high resolution, speed and network connectivity. Thanks to its 300 dpi resolution, expanded memory and compatibility with industrial languages, it is ideal for applications requiring maximum clarity for barcodes and small text.
High-resolution direct thermal printing
The TD-4520DN uses direct thermal technology, eliminating the need for ink or ribbon and reducing maintenance costs. Its 300 x 300 dpi resolution ensures precise results, even on dense labels or those with complex codes.

Print technology: Direct thermal
Resolution: 300 x 300 dpi
Print speed: up to 152 mm per second
Maximum print length: 3,000 mm

Professional print width for multiple applications
Its wide print width allows it to handle large-format labels, making it suitable for shipping, product identification, logistics and information labelling.

Maximum label width: 118 mm
Maximum print width: 108 mm
Integrated label detection sensor

Professional USB, serial and network connectivity
The Brother TD-4520DN is designed for easy integration into existing systems thanks to its multiple connection interfaces, making it ideal for integration projects and corporate environments.

USB 2.0 Full Speed Type B
RS-232C serial port (DB9 male)
Wired Ethernet 10/100Base-TX

Expanded memory and advanced data management
Thanks to its internal memory, the printer can handle complex jobs, databases and graphics without compromising performance.

Flash Memory : 64 MB
MEMORY RAM: 256 MB
Loading databases from PC

Compatibility with industrial languages and software
The TD-4520DN is compatible with the main printing languages on the market, making it easy to replace equipment without modifying existing systems.

Supported commands: ESC/P, Raster, P-touch Template, ZPL II
Additional emulations: CPCL and SBPL (JP model)
Compatible with BarTender software
Includes P-touch Editor and P-touch Editor Lite LAN

Extensive barcode support
It supports a wide variety of symbologies, both linear and two-dimensional, making it a versatile tool for traceability and control.

1D codes: CODE39, CODE128, EAN-8, EAN-13, UPC-A, UPC-E, ITF, GS1-128, GS1 Databar, MSI, POSTNET, Intelligent Mail Barcode
2D codes: QR Code, PDF417, MicroPDF417, Data Matrix, Maxicode, Aztec

Compact design and simple operation
Its compact format allows it to be installed on counters or workstations with limited space, while maintaining fast and reliable operation.

LED control panel with buttons: Power and Feed
LED indicators: Power, Data and Status
Dimensions: 108 x 155 x 224 mm (H x W x D)
Weight: 2.08kg

Operating system compatibility
The printer is compatible with a wide range of platforms, making it easy to integrate into mixed environments.

Windows 7, 8, 8.1, 10 and Windows Server 2008 / 2008R2 / 2012 / 2012R2 / 2016
Linux
Android 4.0.3 or later
iOS 8 or later

Accessories and consumables available
It can be expanded with optional accessories to suit different workflows.

Label remover PALP002
Cutter PACU001
Wide range of Brother continuous thermal paper rolls and self-adhesive labels

Box contents

Brother printer TD-4520DN
AC adapter and power cable
USB Cable
User's Guide
Warranty card

warranty

3-year standard warranty
Volume (m ³): 0.0223
