EPSON Large-format photo printer with dual roll and automatic take-up SURECOLOR-SC-P6500DE 24-PULGADAS DSP0000025719

Features of the Epson SureColor P-Series 24" printer with dual roll and automatic take-up
The Epson SureColor P-Series 24" printer is designed for professional environments that need a precise, versatile large-format solution for demanding design, CAD, graphic production, photography and technical documentation work. Equipped with a PrecisionCore Micro TFP printhead, 6-colour Ultrachrome Pro6 ink, support for rolls up to 24" and an automatic take-up reel, it provides a more efficient workflow for users who require quality, continuity and control with every print.
PrecisionCore Micro TFP technology for professional printing
The PrecisionCore Micro TFP printhead is designed to deliver sharp results in large-format printing, for both graphic and technical applications. Its configuration of 1.600 nozzles per colour and variable-size ink droplet technology enable precise printing of lines, text, images and detailed graphics.

Printing method: PrecisionCore Micro TFP printhead
Nozzle configuration: 1.600 nozzles per colour
Maximum droplet size: 3,5 pl
Variable-size ink droplet technology
Print resolution: 1,200 x 2,400 dpi
Draft resolution: 300 x 300 dpi
Speed mode resolution: 300 x 600 dpi
Maximum quality resolution: 1,200 x 2,400 dpi

6-colour Ultrachrome Pro6 ink system
Ultrachrome Pro6 ink technology uses pigment inks to deliver professional colour reproduction, with a 6-colour configuration combining blacks, basic colours and grey. This composition is particularly useful for work requiring colour stability, good shadow detail and consistent results in visual and technical documents.

Ink technology: Ultrachrome Pro6
Number of colours: 6 colours
Colours: pigment photo black, pigment matte black, pigment cyan, pigment yellow, pigment magenta and pigment grey
Ink tank capacity: 350 ml and 700 ml
Available capacities: Photo Black 350 ml and 700 ml
Available capacities: Matte Black 350 ml and 700 ml
Available capacities: Cyan 350 ml and 700 ml
Available capacities: Yellow 350 ml and 700 ml
Available capacities: Magenta 350 ml and 700 ml
Available capacities: Red 350 ml and 700 ml
Available capacities: Grey 350 ml and 700 ml

Precision for CAD, plans and technical work
This printer is designed for applications where line precision is essential, such as plans, diagrams, CAD documentation or technical designs. Its minimum line width of 0,02 mm and compatibility with professional emulations make it easy to integrate into technical workflows.

Minimum line width: 0,02 mm
Line accuracy : +/- 0,26
CAD print speed on A1 size: fast mode 2 ppm
Colour profiles: LUT and ICC Profile
Emulations: ESC/P-R, PDF 1.7, HP-GL2 and RTL

Wide compatibility with paper formats
The Epson SureColor P-Series can handle a wide variety of formats, from small sizes such as A5 to large formats such as A1. It also supports 17", 24" and other standard roll sizes, making it suitable for studios, technical departments and professional production environments.

Supported formats: A5 14,8 x 21,0 cm
Supported formats: A4 21,0 x 29,7 cm
Supported formats: A3 29,7 x 42,0 cm
Supported formats: A2 42,0 x 59,4 cm
Supported format: A1
Compatible with 43,2 cm 17 in
Compatible with 70 cm 24 in
Printable roll length: 91,5 minimum

Advanced paper handling, dual roll and automatic take-up
One of the highlights of this model is its ability to work with dual rolls and an automatic take-up reel, improving continuity for long or repetitive jobs. It also supports cut sheets, rolls and rigid media, offering greater flexibility for different types of production.

Cut-sheet thickness: 0,1 mm
Roll thickness: 0,8 mm
Rigid media supported
Suitable paper thickness: 0,1 mm - 1,5 mm
Auto Take Up Reel: YES
Roll capacity, roll 1 diameter: 170 mm
Roll capacity, roll diameter 2: 170 mm
Roll capacity, roll weight 1: 6,800 g
Roll capacity, roll weight 2: 6,800 g
Integrated automatic take-up reel

Borderless printing for professional finishes
Borderless printing delivers cleaner finishes for signage, photography, visual designs and professional presentations. This feature is available with different roll widths, helping you adapt the final result to the type of project.

Borderless printing enabled at 20 inches
Borderless printing on 10" 25.4 cm roll
Borderless printing on 17" 43.1 cm roll
Borderless printing on 24" 60.9 cm roll

Comprehensive connectivity for modern workflows
The printer is ready to integrate into professional environments with USB, Ethernet and WiFi 5 connectivity. It also supports printing from PC, Mac, network, mobile devices, cloud and direct USB, making it easy to access the device from different workstations and sources.

Print source: PC, MAC, Network, Mobile Device, Cloud and Direct USB
High-speed USB compatible with specification USB 2.0
Ethernet interface: 1000 Base-T, 100-Base TX and 10-Base-T
IEEE 802.11a/b/g/n/ac WiFi 5 wireless LAN
Network: wired and wireless
Integrated Bluetooth
Mobile and cloud printing services: Apple AirPrint, Epson Cloud Solution PORT and Epson Smart Panel App

Touchscreen and direct printing from USB
The colour LCD touchscreen makes it easy to control the device and access its main functions. In addition, direct printing from USB enables a more efficient workflow when you do not always want to rely on a computer, while the driver preview helps you check jobs before printing.

Color LCD screen
Touch panel
Screen diagonal: 11 cm
Direct printing from USB
Driver preview
Nozzle verification technology
MEMORY : 4 GB

Advanced security for professional environments
This model incorporates security and access control features designed for shared or corporate environments. It includes encryption, authentication, user control and compatibility with network protocols, helping to protect information and manage device usage.

Security: SNMP, IPSec, AES-128 and AES-256
Data storage encryption
Data encryption
WPA3
NFC reader for card authentication
TPM Trusted Platform Module
PIN code release
Image overwrite
User authorisation
LDAP
IEEE802
SSL/TLS

Optional Epson software and solutions
The printer is compatible with various Epson software solutions designed for automation, administration, control and print management. These tools make it possible to adapt the device to professional workflows, from device management to cost control or automated printing.

Optional software: Epson Print Automate
Optional software: Epson Edge
Optional software: Epson Cloud Solution PORT
Optional software: Epson Print Layout
Optional software: Epson LFP Accounting Tool
Optional software: Epson Device Admin
Optional software: Epson Edge Dashboard
Optional software: Epson Print Admin
Optional software: Epson Print Admin Serverless

Robust design for large-format production
With dimensions of 1,365 x 499 x 975 mm and a weight of 118 kg, this printer is designed for professional installations that need stable equipment ready for large-format jobs. Its power consumption of 70 W during operation maintains a good balance between performance and efficiency in its category.

Product dimensions: 1,365 x 499 x 975 mm
Weight: 118 kg
Power consumption : 70 W
Standby power consumption : 0,3 W
Supply voltage: AC 100 V - 240 V, 50 Hz - 60 Hz
Operating sound power : 46 B A
Standby acoustic power : 6,3 B A

Operating system compatibility
The Epson SureColor P-Series is compatible with Windows and macOS systems, making it easy to integrate into creative studios, technical departments, professional offices and environments where different work platforms coexist.

Compatible operating systems: Mac OS X
Compatible with Windows 10
Compatible with Windows 11
Compatible with macOS 11 or later

Included contents and optional accessories
The unit includes the items needed to get started, such as an ink set, maintenance box, documentation and warranty. Its capabilities can also be expanded with optional accessories such as a 1 TB SSD, production stacker or additional paper roll feed spindle for 24" paper rolls.

Includes ink set
Includes maintenance box
Includes maintenance boxes
Includes installation instructions
Includes SureColor P-Series printer
Includes user manual on CD
Includes warranty documents
Optional extras: Cover Plus warranty extensions
Optional extra: SSD solid-state drive
Optional extra: production stacker
Optional extra: paper roll feed spindle, 60.9 cm 24 in
Optional storage: SSD of 1 TB

Other specifications

Product designed for professional large-format printing
Pigment ink technology
Compatible with LUT and ICC Profile colour profiles
Key features: touchscreen, Bluetooth, direct printing from USB, driver preview, automatic take-up reel and nozzle verification technology
Included interfaces: Hi-Speed USB, Ethernet and Wi-Fi 5 wireless
Compatible services: Apple AirPrint, Epson Cloud Solution PORT and Epson Smart Panel App
Optional storage : 1TB SSD
Compatible network: Wired and Wireless
Volume (m ³): 1.3289
