STARTECH.COM Cisco Meraki-compatible RJ45 copper SFP transceiver module MASFP1GBTXST 1000BASE-T 100M DSP0000043644

Features of the Cisco Meraki-Compatible SFP Transceiver Module MA-SFP-1GB-TX
The MASFP1GBTXST SFP transceiver module is a network connectivity solution designed to provide a reliable and stable Gigabit Ethernet connection in compatible Cisco Meraki equipment. This 1000BASE-T copper transceiver converts an SFP port into an RJ45 connection, enabling the use of Cat5e or Cat6 network cabling at speeds of 10/100/1000 Mbps and distances of up to 100 meters. Thanks to its compatibility with Cisco Meraki devices and equipment supporting the MSA standard, it is suitable for expanding or adapting enterprise network infrastructures.
Compatibility with Cisco Meraki and MSA network equipment
This SFP transceiver compatible with Cisco Meraki MA-SFP-1GB-TX has been designed, programmed and tested to work with compatible routers and switches from the brand. It offers an alternative for integrating copper Ethernet connections into devices with SFP ports, while maintaining compatibility with the manufacturer's requirements. It can also be used with MSA-compatible equipment that supports uncoded modules.

Product reference: MASFP1GBTXST.
Compatible OEM reference: Cisco Meraki MA-SFP-1GB-TX.
Compatible brand: Cisco Meraki.
Compatible equipment listed: Cisco Meraki MS225, MX400 and MS250.
Additional compatibility: MSA-compatible switches from Ubiquiti, D-Link, Netgear, Supermicro and TP-Link that support uncoded modules.
Requirements: MSA-compatible or Cisco Meraki SFP port.
Applications: compatible Gigabit network equipment and media converters.

Gigabit Ethernet connectivity up to 100 metres
Thanks to its 1000BASE-T technology over copper cabling, this module enables Ethernet connections at speeds of up to 1000 Mbps. Its RJ45 interface makes it easy to integrate with existing structured cabling installations, while its range of up to 100 metres allows network equipment located in different areas of an office or professional facility to be connected.

Transceiver type: SFP to RJ45.
Network Technology: 1000BASE-T.
Supported network speeds: 10/100/1000 Mbps.
Maximum transfer speed: 1000 Mbps (1 Gbps).
Transmission medium: cobre.
Compatible cabling: Cat5e and Cat Ethernet 6.
Maximum transmission distance: 100 m (328 feet).
Operating mode: Full-Duplex.
Automatic MDIX: sí.
Digital diagnostics monitoring (DDM): Not supported.

Easy installation and hot swapping
The hot-swappable SFP design allows the transceiver to be inserted into or removed from compatible network equipment without having to power off the host device. This feature simplifies maintenance, replacement and connection expansion, reducing interruptions when managing network infrastructures.

Form factor: SFP transceiver module.
Ethernet interface: RJ45.
Host connection: compatible SFP port.
Installation: Hot-swappable (Hot-Swap).
Compatibility: tested to work with compatible OEM devices.

Compatibility with Ethernet standards
This module complies with IEEE standards for 10, 100 and 1000 Mbps Ethernet networks, allowing it to operate at different connection speeds in compatible infrastructures. Its support for automatic MDIX makes it easy to connect using Ethernet cabling without having to manually select the cable type according to the device configuration.

IEEE 802.3i : 10BASE-T.
IEEE 802.3u : 100BASE-TX.
IEEE 802.3ab : 1000BASE-T.
Communication mode: Full-Duplex.
Automatic connection detection: Auto-MDIX.

Compact design and low power consumption
Its silver-coloured aluminium housing combines a compact form factor with a structure suited to integration into network equipment. Weighing just 21 grams and consuming less than 1.3 W, this transceiver is designed for professional installations requiring efficient connectivity and optimised use of space.

MATERIAL: aluminio.
COLOR: plata.
Length: 68 mm (2.7 inches).
Width: 18 mm (0.7 inches).
Height: 13.8 mm (0.5 inches).
Weight: 21 g (0.7 oz).
Input voltage : 3,3 V CC.
output voltage : 3,3 V CC.
Power consumption: Less than 1,3 W.

Reliable operation in professional environments
The transceiver is designed to operate within a temperature range of 0 °C to 70 °C, adapting to the usual operating conditions of communications equipment. Its high mean time between failures (MTBF) and lifetime warranty make it well suited to network installations requiring operational continuity and reliability.

Operating temperature: 0 °C to 70 °C (32 °F to 158 °F).
Storage temperature: -40 °C to 85 °C (-40 °F to 185 °F).
Relative humidity: From 5 % to 95 %.
Mean time between failures (MTBF): 4.655.371 hours.
Warranty: lifetime.

Package contents and other specifications
The product is supplied as a single SFP transceiver unit, ready for integration into compatible devices. Its compact packaging makes the component easy to store and transport for new installations, expansions or replacements in existing networks.

Package contents: 1 SFP transceiver.
Quantity per pack: 1 unit.
UPC identifier: 065030869461.
Package width: 11.4 cm (4.5 inches).
Package depth: 93 mm (3.7 inches).
Package height: 33 mm (1.3 inches).
Shipping weight: 50 g (1.8 oz).
Host connectors listed in the specifications: 1 x RJ45 for host 1 and 1 x RJ45 for host 2.
