D-LINK 48-port Gigabit PoE stackable managed switch and 4 SFP+ DGS-1530-52P 10G MGS0000035151

Features of the D-Link DGS-1530-52P
The D-Link DGS-1530-52P is a stackable Smart Managed switch designed for professional networks requiring high capacity, PoE power and advanced management. With 48 Gigabit PoE ports, 4 10G SFP+ links and a 370 W PoE budget, it is a suitable solution for businesses, educational institutions, hotels and environments with access points, IP cameras or VoIP phones.
48 Gigabit PoE ports and uplinks 10G SFP+
This switch offers comprehensive connectivity for high-performance networks, combining 48 Gigabit Ethernet PoE ports for end devices and 4 10G SFP+ ports for trunk links or connections to servers and aggregation switches.

48 1GE PoE ports
4 ports 10G SFP+
Switching capacity of 176 Gbps
Maximum packet forwarding rate of 130.95 Mpps

Flexible PoE power for professional devices
Thanks to IEEE 802.3af/at support, the DGS-1530-52P can power access points, IP cameras and VoIP phones via the Ethernet cable itself. Its 370 W PoE budget makes it easier to plan demanding installations.

IEEE 802.3af/at PoE
Up to 30 W per port
PoE budget of 370 W
Compatible with Perpetual PoE and Fast PoE
PoE budget expandable up to 740 W with DPS-700 RPS

Physical stacking to grow with the network
The physical stacking function allows several switches to be grouped so they operate as a single logical unit. This simplifies management, improves scalability and helps maintain service continuity in the event of failures.

Physical stacking of up to 9 switches
Master switch failover
Hot-swappable support
Shortest path forwarding

Centralized management and automatic provisioning
The switch can be managed through Nuclias Network Controller, simplifying network control from a centralized platform. In addition, the ZTP function reduces deployment time and minimizes configuration errors.

Management through Nuclias Network Controller
ZTP, Zero-Touch Provisioning
SIM function for managing multiple switches under a single IP address
Automatic firmware or configuration download from a TFTP server

Advanced security for business networks
The DGS-1530-52P incorporates security features designed to protect data and control network access. Its VLAN, ACL, Port Security, 802.1X and RADIUS tools help segment traffic and strengthen user management.

VLAN for network segmentation
ACL for access control
Port security
Authentication 802.1X
RADIUS compatibility

High availability and fault recovery
For environments where continuity is essential, this model integrates technologies such as ERPS G.8032, a redundant power supply and OAM tools for fault detection and resolution.

Ethernet Ring Protection Switching, ERPS
G.8032 ring recovery in very short times
IEEE 802.1ag for Connectivity Fault Management
ITU-T Y.1731 for delay measurement
Compatible with RPS redundant power supply

Electrical protection and rack-mount design
All RJ-45 ports feature 6 kV surge protection, improving stability in professional installations. Its 440 x 250 x 44 mm form factor facilitates integration into rack cabinets.

6 kV IEC61000-4-5 protection on all Ethernet ports RJ-45
Rack-mountable design
3 smart fans
Internal power supply
Weight: 4.35 kg

Other specifications

Maximum power consumption: 482 W with PoE enabled
Maximum power consumption: 59.2 W with PoE disabled
Dimensions: 440 x 250 x 44 mm
Operating temperature: -5°C to 50°C
Storage temperature: -20°C to 70°C
Operating humidity: 0% to 95% non-condensing
Storage humidity: 0% to 95% non-condensing
Console port RJ-45
Power supply type: Internal
Volume (m ³): 0.0099
