IP-COM 16-port unmanaged Gigabit rack switch G1016G L2 1U MGS0000022919

IP-COM Networks Switch Features G1016G
The IP-COM Networks G1016G is an unmanaged Layer 2 switch designed to provide stable, high-performance Gigabit connectivity in business networks, offices, classrooms, retail stores or small data centres. With its 16 Gigabit Ethernet ports, 1U rack-mount form factor and plug-and-play operation, it is a reliable solution for expanding wired networks without complex configuration.
Gigabit connectivity for demanding networks
This switch features 16 RJ-45 Gigabit Ethernet ports (10/100/1000 Mbps) for connecting computers, servers, access points or storage systems with fast, stable data transfers. It supports full duplex and automatic speed negotiation for optimum performance on every port.

16 Gigabit Ethernet ports (10/100/1000 Mbps)
Full duplex
Auto MDI / MDI-X for direct cable connection
Compatible with Cat3, Cat4, Cat5 and Cat5e cables

High performance and non-blocking switching
The IP-COM G1016G offers a switching capacity of 32 Gbit/s and a forwarding rate of 23,8 Mpps, ensuring smooth traffic even when all ports are operating simultaneously. Its store-and-forward architecture improves packet forwarding reliability.

Switching capacity: 32 Gbit/s
Forwarding rate: 23,8 Mpps
Store-and-forward architecture

Unmanaged operation and immediate use
As an unmanaged switch, the G1016G is designed for quick and easy installation. It requires no prior configuration: simply connect it to the network to get started, making it ideal for users seeking simplicity, reliability and low maintenance.

Switch type: unmanaged
Switch cover: L2
Automatic learning and auto-aging of MAC addresses

Professional rack-mount design
Its steel metal housing and 1U form factor allow it to be easily installed in standard 19-inch racks, providing durability and effective heat dissipation. It includes LED indicators for monitoring power, link and network activity.

Rack mounting: Yes
Form factor: 1U
Housing material: steel
LED indicators: Power, Link and Activity

Energy efficiency and stable operation
The switch is designed for low energy consumption, at just 9,2 W, and high reliability, with an MTBF of 100.000 hours. It operates reliably across a wide temperature and humidity range, making it suitable for professional environments.

Energy consumption : 9,2 W
MTBF: 100.000 h
Operating temperature range: 0 °C to 40 °C
Operating humidity range: 10% to 90%

Other technical specifications

MAC address table: 8.000 entries
Network standards: IEEE 802.3, 802.3ab, 802.3u , 802.3x
Flow control support
Power supply included
AC input voltage: 100 - 240 V / 50 - 60 Hz
PoE: Not supported
Product colour: Bronze
Dimensions: 440 x 178 x 44 mm
Certifications: FCC, CE, RoHS
Ean: 6932392831235
Part Number: G1016G
Volume (m ³): 0.0052
