LEVELONE 16-port Gigabit managed switch and 2 SFP GES-2118 MGS0000022357

GES-2118 Hilbert Smart Lite 18-port Gigabit switch, 16 x Gigabit RJ45, 2 x Gigabit SFP
Model number GES-2118
SKU 52091403101
16 Gigabit Ethernet ports and 2 Gigabit SFP slots
Supports auto-learning and automatic aging of MAC addresses of 8K
9K jumbo frames to increase data transfer speeds
IP multicast filtering via IGMP Snooping V1/V2
802.1Q tag-based VLAN enables network segmentation for improved performance and security
IEEE 802.1p QoS with 4 priority queues
Supports unknown unicast/broadcast/multicast storm control
Minimize your carbon footprint with advanced energy-efficient technology (IEEE 802.3az)
4KV surge protection, 6KV contact/air ESD protection 8KV
Smart web-based management
Supports the LevelOne IP Locator for easier IP management.

The LevelOne Hilbert GES-2118 Smart Lite Gigabit switch is a next-generation Ethernet switch offering powerful, enhanced functionality and usability that provides cost-effective business solutions
and transports Ethernet services over fiber or copper connections. GES-2118 offers 16 (10M/100M/1G) RJ45 ports and 2 Gigabit SFP ports. It can be combined with LevelOne’s latest IP locator, the
software is the easiest-to-use switch discovery tool; it can search for all switches in the Hilbert series and instantly find a forgotten IP address and other information.
Compatible with major Windows and Mac operating systems.

The LevelOne GES-2118 provides high hardware performance and environmental flexibility for businesses. GES-2118 is ideal for delivering simple management, an optimal user experience and lower cost
of ownership.
general
black
EAN 4015867229262
Model number GES-2118
Characteristic
Switching functions L2
IGMP Snooping
Link aggregation (supports static link aggregation)
Port mirroring
Cable test

VLAN
Supports up to 32 VLANs (of 4K VLAN IDs)
MTU/Port /VLAN 802.1Q

Quality of Service (QoS)
Port/802.1p/DSCP-based priority support
Supports 4 priority queues
Rate limit
Storm Control
Management Web-based graphical user interface (GUI)
Supports the LevelOne IP Locator for easier IP management.
Miscellaneous
Gigabit Ethernet data rate
PoE compatible No
Concurrent ports Total 18.00
Fanless Yes
Manageable Yes
Series HILBERT Series
Commercial grade
Non-disclosure
Integrated system SoC
Others
Approval and Compliance CE
UNITED KINGDOM
FCC Part 15, Subpart B Class B
RoHS
Operating humidity 10% RH ~ 90% RH
Operating temperature 0°C ~ 45°C
Storage humidity 5% RH ~ 95% RH
Storage temperature -40°C ~ 70°C
PACKAGE CONTENT GES-2118
power cord
Rack mounting kit of 19"
Quick installation guide
Declaration of Conformity
performance
Switching Capacity 36 Gbps
Physical Specifications
Dimensions (Width x Depth x Height) 271 x 181,5 x 44,5 mm
Product weight (kg) 1,08 kg
System specifications
Acoustic noise (dB) 0 dB (A)
Backplane (Gbps) 36
Flash memory size 2 MB
Packet forwarding rate 26.784 Mpps
Heat dissipation 51,18 (Btu/H)
Indicators Power, System, Link/Act
Jumbo frame (KB) 9 K
Address Table MAC 8K
Mounting 19" rack mounting, desktop mounting
MTBF 43,800 hours
Packet buffer 4.1 Mbits
Port configuration 16 x 10/100/1000 Mbps RJ-45 copper downlink ports, 2 x 100/1000 Mbps SFP uplink ports
Power consumption 15W
Power supply 100-240 VAC, 50-60 Hz
Standards IEEE 802.3 10-BASE-T (Ethernet)
IEEE 802.3u 100-BASE-TX (Fast Ethernet)
IEEE 802.3ab 1000BASE-T (Gigabit Ethernet)
IEEE 802.3z 1000BASE-X (Gigabit Ethernet)
IEEE 802.3x flow control (full-duplex flow control)
IEEE 802.3az: Energy Efficient Ethernet
Volume (m ³): 2.2195
