IP-COM Layer 3 managed switch with 8 Gigabit ports and SFP slots G5324-16F MGS0000009698

Features of the IP-COM G5324-16F
The IP-COM G5324-16F is a Layer 3 cloud-managed switch designed for professional networks requiring high connection density, fiber aggregation, and advanced security and management features. With 8 Gigabit Ethernet ports, 16 independent Gigabit SFP ports, and a switching capacity of 48 Gbps, it is a suitable solution for the aggregation or core layer in environments such as SMEs, hotels, offices, and enterprise networks.
Gigabit connectivity with 8 RJ45 ports and 16 SFP ports
This switch combines 8 10/100/1000Base-T Ethernet ports with 16 independent 1000Base-X SFP ports, providing flexible connectivity for mixed copper and fiber networks. This configuration meets local access requirements while also facilitating fiber link aggregation in professional installations.

8 10/100/1000Base-T Ethernet ports
16 independent 1000Base-X SFP ports
1 console port
Designed for fiber-optic aggregation

Switching performance for demanding networks
The IP-COM G5324-16F offers a switching capacity of 48 Gbps, enabling smooth network traffic management in environments with multiple connected devices. Its large 12 Mb buffer and 16,000-entry MAC table help maintain stable performance even in high-demand scenarios.

Switching capacity: 48 Gbps
Large buffer: 12 Mb
MAC address table: 16,000 entries
MAC address auto-learning

Layer 3 features for advanced networks
As a Layer 3 switch, this model enables advanced network management features, including IPv4 static routing and a DHCP server. These capabilities make it easier to organize traffic between network segments and provide greater flexibility than a conventional Layer 2 switch.

Supports the IPv4 static routing protocol
Integrated DHCP server
Layer 3 management features
Suitable for aggregation and core networks

VLAN, ACL, and advanced traffic control
The G5324-16F includes service features such as VLAN, ACL, and QoS, enabling network segmentation, access control, and traffic prioritization according to the needs of each environment. This is particularly useful in enterprise networks where users, services, cameras, access points, and corporate systems coexist.

COMPATIBLE WITH VLAN IEEE 802.1Q
MAC ACL support
IPv support 4 ACL
Packet filtering based on configured rules
Improved network control and security

QoS for service prioritization
Quality of Service (QoS) features optimize network traffic and prioritize applications sensitive to latency or bandwidth. The switch supports several scheduling mechanisms, allowing traffic management to be adapted to different professional scenarios.

QoS with SP mode
QoS with WRR mode
QoS with SWRR mode
Traffic prioritization for critical services

STP, RSTP and MSTP for network stability
The device is compatible with STP, RSTP and MSTP, protocols designed to prevent loops and improve infrastructure stability. These features are especially important in networks with multiple switches, redundant links or complex topologies.

STP compatible
RSTP compatible
MSTP compatible
Greater stability in network topologies with redundancy

DHCP services and IGMP Snooping
The IP-COM G5324-16F offers comprehensive DHCP functions to facilitate the assignment and management of IP addresses within the network. In addition, IGMP Snooping support helps optimise multicast traffic, preventing unnecessary transmissions and improving network efficiency.

DHCP server
DHCP Relay
DHCP Snooping
IGMP Snooping
Multicast traffic optimization

IMS cloud management
This switch supports cloud management via IP-COM IMS Cloud, enabling remote network administration and maintenance. This feature helps reduce after-sales service costs and makes it easier to monitor distributed installations from a centralised platform.

Compatible with IMS cloud management
Remote administration and maintenance via IP-COM IMS Cloud
Reduced on-site maintenance costs
Suitable for networks with multiple distributed devices

Local display management
Local visualisation management enables network devices to be discovered and the topology to be generated automatically, facilitating infrastructure diagnostics and monitoring. It also detects whether connected equipment is online or offline.

LLDP-based network device discovery
Detection of routers, switches and access points
IP camera discovery via ONVIF protocol
Automatic topology generation
Detection of device online and offline status

Comprehensive security mechanism
The G5324-16F features an advanced security mechanism to protect the network against unauthorised access and common attacks. Its defences against MAC, ARP and DoS attacks, together with IP and MAC ACLs, allow control rules to be applied and improve the overall security of the infrastructure.

Defence against MAC address attacks
Defence against ARP attacks
DoS Attack Defense
IP ACL support
MAC ACL support

Professional administration and maintenance
The switch offers several professional management options, including a web interface, CLI via console or Telnet, and SNMP. It also includes diagnostic tools such as Ping and Tracert, as well as CPU and memory monitoring to facilitate daily maintenance.

Web management
CLI via console
CLI via Telnet
SNMP v1/v2/v3
Ping test
Tracert test
CPU Monitoring
Memory monitoring

Rack-mount design 1U
The IP-COM G5324-16F features a 1U rack-mount enclosure design, making it easy to install in communications cabinets and technical rooms. This format helps keep infrastructure organised and ready for professional environments with a high connection density.

Rack-mount format
HEIGHT 1U
Design suitable for the aggregation layer
Design suitable for the network core layer

Network standards compatibility
The switch complies with multiple IEEE standards, ensuring compatibility with a wide range of devices and network functions. This compatibility makes it easier to integrate into existing professional infrastructures.

IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3ad
IEEE 802.3z
IEEE 802.3x
IEEE 802.1p
IEEE 802.1Q
IEEE 802.1w
IEEE 802.1d
IEEE 802.1s

Other technical specifications

MODEL: G5324-16F
Product type: cloud-managed switch L3
Ethernet ports: 8 10/100/1000Base-T ports
SFP ports: 16 independent 1000Base-X ports
Console port : 1
Switching capacity: 48 Gbps
Buffer: 12 Mb
MAC address table: 16,000 entries
L3 features: IPv4 static routing and DHCP server
Service features: VLAN, ACL, QoS, IGMP Snooping, SNMP and Telnet
Management: IP-COM IMS Cloud and local display
Recommended scenarios: SMEs, hotels, aggregation layer and network core layer
Volume (m ³): 0.0138
