TP-LINK 8-port Gigabit managed switch OMADA TL-SG2008 JETSTREAM-L2 TPL-TL-SG2008

Gigabit Ethernet connections on all ports providing the
maximum data transfer speed
Integrated security strategy including VLAN 802.1Q, ACL, Security
for Port and Storm Protection that help protect the investment in the
LAN QoS L2 / L3 / L4 and IGMP snooping that optimize the applications of
video and audio
Web/CLI management modes, SNMP, RMON with numerous functions
administration
Innovative energy efficiency technology that saves up to 65% of
Power consumption
Hardware Features
IEEE 802.3i Standards and Protocols, IEEE 802.3u Standards and Protocols, IEEE 802.3ab Standards and Protocols
IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s,
IEEE 802.1w, IEEE 802.1q, IEEE 802.1p
8 Port Interface RJ45 10/100/1000Mbps
(Auto-negotiation/Auto MDI/MDIX)
10Base-T Network Media: UTP cable category 3, 4, 5 (maximum 100m)
100Base-TX/1000Base-T: UTP cable category 5, 5e or higher
(maximum 100m)
Quantity of Fans No Fan
Power Supply 100 ~ 240 VCA, 50/60 Hz
External power adapter (output : 12VDC / 1A)
Maximum Power Consumption: 6.42W (220V/50 Hz)
Dimensions 209 * 126 * 26 mm (8.2 * 4.9 * 1.0 in)
Performance
Backplane / Bandwidth 16Gbps
Packet Forwarding Rate 11.9Mpps
MAC 8k Handlebar Ends
Jumbo Frame 9216 Bytes
SOFTWARE FEATURES
Service Quality Supports 802.1p CoS / DSCP Priority
Supports 4 Priority Tapes
Queue programming: SP, WRR, SP + WRR
Flow / Port-based rate limitation
VLAN for Voice
Features L2 IGMP Snooping V1/V2/V3
LACP 802.3ad (up to 6 aggregation groups, containing 4 ports per group)
Spanning Tree STP/RSTP/MSTP
BPDU Filter/BPDU Guard
Protection TC/Root
Loop Back Detection
Flow control 802.3x
VLAN Supports up to 512 simultaneous VLANs (up to 4K VLAN IDs)
Access Control List L2 ~L4 package filtered based on source and destination
MAC address, IP address, ports TCP/UDP, 802.1P,
DSCP, protocol, and VLAN ID
Based on Time Range
Safety SSH v1 / v2
SSL v2 / v3 / TLSv1
Port security
Storm control / diffusion / multi-diffusion / single-diffusion unknown
802.1xy Radius Authentication IP-Mac-Port-VID Link ARP Inspection
DHCP Defense DoS
Web GUI and CLI based management
SNMP v1/v2c/v3, compatible with public MIBs and TP-LINK private MIBs
RMON (groups 1, 2, 3, 9)
CPU Monitoring
Port Mirroring
Time Adjustment: SNTP
Firmware Update: TFTP and Web
Diagnostic System: APV
SYSLOG and Public MIBS
Others
CE, FCC, RoHS certifications
PACKAGE CONTENT TL-SG2008
Power adapter
Quick installation guide
Resource CD
Gum Feet
System requirements Microsoft Windows 98SE, NT, 2000, XP, Vista or
Windows 7, MAC OS, NetWare, UNIX or Linux.
Environmental Factors Operating Temperature : 0 º C ~ 40 º C (32~
104),
Storage temperature : -40º C ~ 70 º C (-40~ 158)
Operating Humidity: 10% ~ 90% without condensation
Storage Humidity: 5% ~ 90% without condensation
