TP-LINK Dual-band WiFi 5 mesh system DECO M4 AC1200 2 UDS MGS0000012204

Whole-home mesh Wi-Fi system AC1200

Deco uses a system of units to achieve Wi-Fi coverage
perfect throughout your home: eliminate weak-signal areas once and for
all! With advanced Deco Mesh technology, the units work together
to form a unified network with a single network name. The devices
automatically switch between Decos as you move around your home
to get the fastest speeds possible.
A two-pack of Deco M4 provides Wi-Fi coverage for an area of up to 2,800 feet
square feet 260 m2 (EU version). And if that’s not enough, simply
add more Decos to the network at any time to increase the
coverage.
Deco M4 provides fast, stable connections with speeds of
up to 1167 Mbps and works with major Internet service providers
(ISP) and modems.
Deco can handle traffic even on the busiest networks,
providing lag-free connections for up to 100 devices.
Parental controls limit online time and block websites
that are inappropriate, based on unique profiles created for each family member
the family.
Setup is easier than ever with the Deco app guiding you
every step of the way.

Wireless
Wi-Fi 5 standards
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds AC1200
5 GHz: 867 Mbps (802.11ac)
2.4 GHz: 300 Mbps (802.11n)
WiFi Range Homes with 3 to 5 bedrooms (3-pack)Mesh technology
TP-Link
Optional Ethernet backhaul works together to link the units
Deco and provide seamless coverage

2 antennas (internal)
Multiple antennas form a signal-boosting array to cover more
directions and larger areas

Beamforming
Focuses wireless signal strength toward clients to extend the
WiFi range
WiFi Capacity Medium Dual Band
Distribute devices across different bands for optimal performance

MU-MIMO
Communicates simultaneously with multiple MU-MIMO clients
Working Modes Router Mode
Access Point Mode
Hardware
Processor CPU Qualcomm
Ethernet Ports 2 Gigabit ports

*Per Deco Unit
Supports automatic WAN/LAN detection
Buttons Reset button
SECURITY
WiFi Encryption WPA-Personal
WPA2-Personal
Network Security SPI firewall
Access control
Guest Network 1 5 GHz guest network
1 2.4 GHz guest network
SOFTWARE
Protocols IPv4
IPv6
Parental Controls URL Filtering
Time Controls
WAN Types Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service QoS per device
Cloud Service OTA Firmware Update
TP-Link ID
DDNS
NAT Forwarding Port Forwarding
UPnP
IPTV Proxy IGMP
IGMP Snooping
Jumper
VLAN Tagging
DHCP Address Reservation
DHCP Client List
Server
TP-Link DDNS
Management Deco APP
Physical
Dimensions (WDH) 3.6 3.6 7.5 in
(90.7 90.7 190 mm)
Package Contents Deco M4 (3-pack) 3)
3 Deco units M4R
1 Ethernet cable RJ45
3 power adapters
1 quick installation guide

Deco M4 (2-pack) 2)
2 Deco units M4R
1 Ethernet cable RJ45
2 power adapters
1 quick installation guide

Deco M4 (2-pack) 1)
1 Deco unit M4R
1 Ethernet cable RJ45
1 power adapter
1 quick installation guide
Others
System requirements Android 4.4 or later
iOS 9.0 or later
Certifications CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS
Environment Operating temperature : 0 ~ 40 (32 ~ 104 )
Storage temperature : -40 ~ 70 (-40 ~ 158 )
Operating humidity: 10%~90% non-condensing
Storage humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power CE:
<,20 dBm (2.4 GHz)
<,23 dBm (5 GHz)
FCC:
<,30dBm
Volume (m ³): 0.0088
