MERCUSYS 18-port unmanaged switch with PoE+ MS118CP MGS0000030562

Features of the Mercusys Unmanaged Switch MS118CP 18P
The **Mercusys MS118CP** is a high-performance unmanaged switch, ideal for video surveillance environments, offices or network deployments requiring PoE+ power and fast connectivity. With **16 100 Mbps PoE+ ports**, **2 Gigabit RJ45 ports** and **2 Combo SFP slots**, this model offers a reliable, stable and cost-effective solution for powering devices such as **IP cameras, access points or VoIP phones**, all in a rack-mountable 1U design.
High-capacity PoE+ power supply
This switch allows you to connect and directly power up to 16 PoE/PoE+ devices, with a maximum power of 30 W per port and a total power budget of 190 W. It is ideal for surveillance installations or corporate networks requiring a centralised, stable power supply.

Total PoE budget : 190 W
Up to 30 W per port according to IEEE 802.3af/at
Auto Recovery mode for automatically restarting inactive devices

Extended transmission for video surveillance
Thanks to extended mode, the Mercusys MS118CP can exceed the typical 100-metre network cabling limit, reaching up to 250 metres. This feature is specifically designed to cover long distances in surveillance installations or large networks.

Extended mode can be enabled for long-range transmission
Ideal for deployments with remote IP cameras
Stable network even over long distances

Gigabit uplink ports and high performance
The switch features 2 Gigabit RJ45 ports and 2 SFP Combo slots for uplinks, making it easy to connect to routers, NVRs or high-speed network backbones. It also offers a switching capacity of 7.2 Gbps and efficient traffic management for demanding networks.

2x Gigabit RJ45 ports + 2x SFP Combo 1 Gbps
Switching capacity: 7.2 Gbps
MAC table: up to 8,000 addresses

Rack-mountable design with active ventilation
Its metal chassis is designed for rack mounting (1U), making it ideal for communications cabinets. It features 2 internal fans that ensure heat dissipation during continuous operation. Everything needed for professional installation is included.

1U rack format 19"
Dimensions: 440 × 180 × 44 mm
Includes mounting brackets, screws and power cable

Advanced features for demanding environments
With no configuration required, the MS118CP offers features designed to improve network performance: priority mode for the first 8 ports (ideal for real-time video), isolation mode to protect devices, and flow control to prevent congestion.

Priority mode for critical traffic (ports 1-8)
Port isolation mode for greater security
802.3x flow control and store-and-forward transmission

Other specifications

Maximum power consumption: 218.91 W (with full PoE load)
Jumbo frame : 10 KB
Power supply: 100–240V AC, 50/60 Hz (internal power supply)
Certifications: CE, FCC, RoHS
Kensington-type physical security slot
Volume (m ³): 0.0119
