MERCUSYS Dual-band Wi-Fi 6 mesh system HALO-H60X AX1500 3 UDS DSP0000041646

Features of the HALO H60X 3-Pack
The Mercusys Halo H60X 3-Pack is a dual-band WiFi Mesh system with WiFi 6 AX1500 technology, designed to provide a stable, fast and consistent connection throughout your home. Thanks to its three units, it can cover up to 550 m², eliminating dead zones and maintaining a single WiFi network for all your devices.
Dual-band WiFi 6 up to 1500 Mbps
This system features WiFi 6 technology, offering greater efficiency, speed and stability for browsing, working, gaming online or streaming content with several devices connected at the same time.

Total speed AX1500
1201 Mbps on the 5 GHz band
300 Mbps on the 2,4 GHz band
Standards: IEEE 802.11ax/ac/n/a on 5 GHz and IEEE 802.11n/b/g on 2.4 GHz

Whole-home Mesh coverage
Halo units work together to create a unified network with the same WiFi name and password. As you move around your home, the system automatically switches between nodes to maintain a smooth, stable connection.

Coverage up to 6,000 ft² / 550 m²
Ideal for homes with 3 to 5 rooms
Seamless roaming with a unified WiFi network
802.11k/v/r Mesh protocol

Stable connection for more than 100 devices
The Halo H60X is designed for homes with many connected devices, providing a stable network for phones, laptops, TVs, consoles, cameras, smart speakers and other devices.

Supports more than 100 connected devices
WMM QoS to optimise network performance
Guest network on 2.4 GHz and 5 GHz
Compatible with IPv4 and IPv6

Gigabit ports and operating modes
Its Gigabit ports let you take advantage of high-speed wired connections for devices that require maximum stability, such as computers, consoles or Smart TVs.

Halo H60XR: 3 Gigabit WAN/LAN ports
Halo H60XS: 2 Gigabit LAN ports
Operating modes: router and access point
WAN types: Dynamic IP, Static IP, PPPoE, L2TP and PPTP

Easy management from the MERCUSYS app
The system is easy to set up and manage using the MERCUSYS app, which lets you manage your home network, control your children’s online time and monitor the content they access.

Local and remote management
Support for multiple administrators
Time and content controls
Integrated Reset button

Network security and reliability
The system incorporates current security protocols to protect the WiFi connection and keep your home network more secure, including WPA3 and SPI firewall.

Wireless security WPA-PSK / WPA2-PSK / WPA3
SPI firewall
DHCP Server and Client
Transmission power: 2.4 GHz <, 20 dBm EIRP and 5 GHz <, 23 dBm EIRP

Package contents and dimensions
The pack includes three Halo units and everything you need to get started with a quick installation at home.

1 Halo unit H60XR
2 Halo units H60XS
1 Ethernet cable RJ45
3 power adapters
Quick installation guide
Dimensions: 88 x 88 x 88 mm

Other specifications

2.4 GHz sensitivity: 11g 6 Mbps -96.5 dBm, 11g 54 Mbps -78 dBm
5 GHz sensitivity: 11a 6 Mbps -96 dBm, 11a 54 Mbps -78 dBm
5 GHz sensitivity: 11ac VHT20 MCS8 -74.5 dBm, 11ac VHT40 MCS9 -70.5 dBm, 11ac VHT80 MCS9 -66.5 dBm
5 GHz sensitivity: 11ax HE20 MCS11 -66 dBm, 11ax HE40 MCS11 -63 dBm, 11ax HE80 MCS11 -61 dBm
Operating temperature : 0°C ~ 40°C
Operating Humidity: 10% ~ 90% without condensation
Storage Humidity: 5% ~ 90% without condensation
Note: the Halo H series and the Halo S series cannot work together
Volume (m ³): 0.0069
