ZYXEL 24-port Gigabit L3 PoE managed rack switch XGS2220-30HP 2X 10G 4X-SFP+ DSP0000025501
DeliveryUpdating delivery estimate…Order within the next — to receive it approximately Updating delivery estimate…
Updating delivery estimate…
Cuándo es más probable que llegue
Calculado con 0 entregas recientes
Fechas estimadas para España peninsular; se ajustarán con tu código postal y forma de entrega.
The date corresponds to the item with the longest delivery time
IVA intracomunitario
La exención intracomunitaria puede aplicarse a una entrega a otro Estado miembro si el NIF-IVA es válido y el destino cumple los requisitos. La comprobación por sí sola no determina el tratamiento fiscal.
Cómo se comprueba el IVA¿Eres profesional del sector?
Puedes solicitar una cuenta profesional e indicar los datos de tu actividad. La solicitud queda pendiente de revisión; puedes consultar su estado en tu cuenta.
Más información sobre cuentas profesionalesCanarias, Ceuta y Melilla sin IVA español
El tratamiento depende del destino de entrega y de la coherencia de la dirección. Pueden corresponder IGIC, IPSI, aranceles u otros cargos locales.
Más información sobre destinos e impuestosNumber of basic RJ-45 Ethernet switching ports 24
Basic switching ports, RJ-45 Gigabit Ethernet (10/100/1000)
Number of SFP+ modules installed 4
Number of 10G Ethernet (copper) ports 2
WEIGHT AND DIMENSIONS
Width 441 mm
Depth 330 mm
Height 44 mm
Weight 4,35 kg
Power control
Power supply included Yes
Input voltage AC 100 - 240 V
AC input frequency 50 - 60 Hz
Power consumption (ma x) 477 W
Power source AC
Environmental conditions
Operating temperature range -20 - 50 C
Operating relative humidity 10 - 95%
Storage temperature range -40 - 70 C
Storage relative humidity 10 - 90%
Heat dissipation 1626,57 BTU/h
Technical details
Sustainability certificates RoHS, United States Federal Communications Commission (FCC), Low Voltage Directive (LVD), CE
Protocols
GARP VLAN Registration Protocol (GVRP) Yes
Connection
Network standards IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3x, IEEE 802.3z
10G support Yes
Input routing 64
Data transmission
MAC address table 32000 entries
Jumbo Frames support Yes
Switching capacity 168 Gbit/s
Forwarding rate 125 Mpps
Packet buffer 2 MB
Static route Yes
Packaging
Package weight 5,77 kg
Package width 580 mm
Package depth 503 mm
Package height 95 mm
SECURITY
DHCP features DHCP relay, DHCP server
IGMP Yes
Supported security algorithms SNMP, SNMPv2, SNMPv3
BPDU protection and filtering Yes
Authentication type IEEE 802.1x, RADIUS, TACACS+
IGMP proxy Yes
Management features
Switch type Managed
Quality of Service (QoS) support Yes
Web-based administration Yes
Switch cover L3
ARP inspection Yes
Cloud-managed Yes
Design
Rack mounting Yes
Product colour Black
LED indicators Yes
Power over Ethernet (PoE)
PoE Yes
Power over Ethernet (PoE) budget 400 W
Number of Power over Ethernet ports (Po E) 26
Performance
Internal memory 1024 MB
Flash Memory 64 MB
Mean time between failures 268,305 h
Multicast functions
Multicast support Yes
Multicast Listener Discovery (MLD) MLD v1/v2
Volume (m ³): 0.0099
- Brand
- ZYXEL
- Reference
- DSP0000025501
- EAN-13
- 4718937625055
- Weight
- 2,225 kg
