STARTECH.COM Single-mode fiber-optic SFP transceiver 100BASE-LX 1310NM 10KM LC SFP100BLXST DSP0000033440

Features of the StarTech.com 100Base-LX Single-Mode LC Fiber SFP Transceiver Module
The **StarTech.com SFP transceiver module** is designed to provide a reliable, efficient fiber-optic connectivity solution compatible with equipment using SFP interfaces. Thanks to its compact design and compliance with the **100Base-LX** standard, it is ideal for enterprise LANs requiring **long-distance transmission** over single-mode cabling. Its compatibility with MSA and digital diagnostic technologies makes it a versatile, professional choice.
Stable long-distance connectivity
This transceiver enables highly reliable network links over distances of up to **10 kilometers** using single-mode fiber-optic cable. It also supports speeds of up to **100 Mbps**, ensuring suitable performance for critical network applications.

Transfer speed: up to 100 Mbps
Maximum range: 10 km over single-mode fiber
Connector type: LC (single-mode, duplex)

MSA compatible with digital diagnostics (DDM/DOM)
Thanks to its compatibility with the **MSA (Multi-Source Agreement)** standard, this module can be seamlessly integrated into a wide range of network devices. It includes support for **Digital Diagnostics Monitoring (DDM)** and **Digital Optical Monitoring (DOM)**, allowing critical parameters such as temperature, optical power and voltage to be monitored for more precise network management.

MSA compliant for broad compatibility
Integrated DDM and DOM diagnostic functions
Supports full-duplex and half-duplex modes

Compact and sturdy design
The SFP form factor makes installation easy in compatible devices, even in space-constrained environments. Its silver-colored metal housing provides good heat dissipation, and it is manufactured to operate across a wide temperature and humidity range.

Compact design: only 5,84 cm deep
Operating temperature range: from 0 °C to 70 °C
Operating humidity: 5% to 95%

Other specifications

Silver color
Weight: 30g
Dimensions: 5,84 cm (depth) x 1,39 cm (width) x 1,26 cm (height)
Device type: SFP transceiver module (mini-GBIC)
Connectivity technology: Wired
Protocol: 100Mb LAN
Optical wavelength: 1310 nm
Compliance with regulations: FCC, RoHS, WEEE, RCM, IEEE 802.3u
Volume (m ³): 0.0099
