TP-LINK WiFi 6 and Bluetooth PCIe network card ARCHER-TX50E AX3000 TPL-ARCHERTX50E

AX3000 PCIe Wi-Fi 6 Bluetooth adapter 5.0

Unmatched Speed Wi-Fi 6Break the gigabit barrier with speed
of up to 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz)
Smooth Experience75% less latency ensures ultra-responsive
gaming, uninterrupted video calls and perfect live streaming
Secure ConnectionsThe Intel® Wi-Fi 6 chipset delivers faster, cleaner Wi-Fi
that unlocks the full potential of your Wi-Fi 6 router
Wider Signal Coverage Connect to your Wi-Fi in more areas of your home
with the 2 high-gain external antennas that ensure wide coverage and
Improved stability
Bluetooth 5.0The latest Bluetooth technology delivers faster speeds 2×
and 4× wider coverage than the BT 4.2
Enhanced SecurityThe latest WPA3 security enhancements provide
enhanced security for personal passwords
Detailed DesignThe specialized heat sink and gold plating
are designed to improve stability and reliability even in
hot environments
Backward Compatibility Full support for the standards
802.11ac/a/b/g/n
Hardware Features
Dimensions 95.2 x 120.8 x 21.5 mm
(3.7 x 4.8 x 0.8 in)
Antenna Type Two High-Gain Dual Band Antennas
Chipset Intel Wi-Fi 6 Chipset
WIRELESS FEATURES
Wireless Standards IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/g/b 2.4 GHz
Bluetooth 5.0/4.2/4.0
WLAN Signal Rate 5 GHz
11ax: Up to 2402 Mbps(dynamic)
11ac: Up to 1733 Mbps(dynamic)
11n: Up to 300 Mbps(dynamic)
11a: Up to 54 Mbps(dynamic)

2.4 GHz
11ax: Up to 574 Mbps(dynamic)
11n: Up to 300 Mbps(dynamic)
11g: Up to 54 Mbps(dynamic)
11b: Up to 11 Mbps(dynamic)
WLAN Reception Sensitivity 5 GHz :
11ax HT160-56.25dBm
11ax HT80: -59dBm
11ax HT40: -62.25dBm
11ax HT20: -65dBm

11ac HT160-62dBm
11ac HT80: -65.5dBm
11ac HT40: -69.75dBm
11ac HT20: -73.75dBm
11n HT40: -74.5dBm
11n HT20: -77.5dBm
11a 54Mbps: -77.75dBm
11a 6Mbps: -94.5dBm

2.4GHz :
11ax HT40: -60.75dBm
11ax HT20: -63.75dBm
11n HT40: -73dBm
11n HT20: -76.25dBm
11g 54Mbps: -76.5dBm
11b 11Mbps: -89dBm
WLAN Transmit Power 5 GHz : 27dBm(FCC) / 23dBm(CE) (EIRP)
2.4 GHz: 26dBm(FCC) / 20dBm(CE) (EIRP)
WLAN Modes Infrastructure mode
Wireless Security 64/128 bit support WEP, WPA/WAP2/WPA3, WPA-
PSK/WPA2-PSK, 802.1x
Modulation technology DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-
QAM, 1024QAM
Bluetooth Profiles Archer TX50E supports the native BT profiles implemented in
Windows 10.
For the latest information on BT profiles in Windows 10, see:

bluetooth-profiles
Others
CE, FCC, RoHS certifications
Archer Package Contents TX50E
Two high-gain 5 dBi antennas
Low-profile bracket
Bluetooth Header Cable
Quick installation guide
Resource CD
System requirements: Windows 10 (64-bit) only
Environmental Factors Operating Temperature : 0~40 (32~104)
Storage temperature : -40~70 (-40~158)
Operating humidity: 10%~90% non-condensing
Storage humidity: 5%~90% non-condensing
Volume (m ³): 0.0012
