STARTECH.COM PCI Express network card with 2 2.5 Gigabit ports and PoE INTEL-I225-V RJ45 PR22GIP-NETWORK-CARD DSP0000039361

Features of the Startech 2-Port 2.5Gbps PoE Network Card Intel I225-V
The Startech 2-port 2.5Gbps PoE network card is an advanced solution designed to expand connectivity for professional equipment and servers. Thanks to its Intel I225-V controller and PoE power capability, it enables efficient management of network devices, combining high performance, versatility and energy efficiency. It is ideal for business environments, virtualization or demanding network configurations.
High-performance 2.5GbE connectivity
Equipped with two 2.5Gbps Ethernet ports, this card multiplies network capacity compared with traditional Gigabit solutions. It enables faster, more stable transfers, making it perfect for servers, advanced workstations or NAS environments.

2 2.5 Gigabit Ethernet RJ-45 ports
Transfer speed of up to 2.5 Gbps
Network compatible 10M / 100M / 1G / 2.5G

Integrated PoE support (IEEE 802.3af/at)
Thanks to its Power over Ethernet (PoE) functionality, this card can power devices directly through the network cable, eliminating the need for additional power supplies and simplifying installation.

Compatible with IEEE 802.3af and 802.3at
PSE (Power Sourcing Equipment) function
Dedicated power connectors (LP4 and 6+2-pin)

Efficient architecture with Intel chipset
The Intel I225-V chip ensures reliable connectivity, low latency and excellent compatibility with modern operating systems. It also incorporates advanced features that optimise traffic and network management.

Support for VLAN, QoS and Jumbo Frames (up to 9000)
Auto-negotiation and full-duplex mode
Advanced features such as WOL, PXE and EEE

Broad compatibility and professional use
Designed for integration into professional environments, this card is compatible with Windows, Linux and virtualisation platforms, making it a versatile option for IT infrastructures.

Compatible with Windows 10/11 and Windows Server
Support for VMware ESXi 7.0
Compatible with Linux 5.8.x LTS or later

Functional design and easy integration
Its PCIe 2.0 x2 card format allows easy installation in a wide range of equipment. It also includes a low-profile bracket to fit different types of chassis.

PCI Express interface 2.0 x2
Includes low-profile bracket
Integrated heatsink for improved cooling

Other specifications

LED indicators: PoE, link/activity, speed
Standards: IEEE 802.3, 802.3ab, 802.3bz, 802.1Q, 802.1p, among others
Operating temperature: 0 °C to 55 °C
Humidity : 5 - 90% RH
Dimensions: 12.1 x 18 x 2.2 cm
Weight: 111g
COLOUR: BLACK
Complies with RoHS and WEEE regulations
Volume (m ³): 0.0011
