EINAREX Semi-modular ATX PC power supply APEX-L1 650W DSP0000043309

Features of the Einarex Apex L1 ATX 650W Black Power Supply
The Einarex Apex L1 650W is an Intel ATX 12V form factor power supply designed to provide power to the components of a desktop computer. It has Cybenetics Bronze certification, a set of electrical protections and various connections to facilitate the installation of internal components.
650W power and certified efficiency
With a total power output of 650W, this power supply can power PC configurations that meet its electrical requirements. Its Cybenetics Bronze certification attests to its energy efficiency level, while the inclusion of active PFC helps improve the power factor during operation.

Total power: 650W.
Efficiency certification: Cybenetics Bronze.
Power factor correction: active PFC.
Format: Intel ATX 12V.

Connectivity for PC components
The Einarex Apex L1 features a selection of connectors for supplying power to the motherboard, processor, graphics cards and storage drives. Its 6 SATA connectors allow several compatible drives and peripherals to be connected, while the PCI-E and EPS12V connectors provide power options for other internal components.

1 24-pin main ATX connector for motherboard.
2 8/4-pin EPS12V connectors for CPU.
2 8/6-pin PCI-E connectors.
6 SATA connectors.
2 4-pin peripheral connectors.

Integrated electrical protections
This power supply includes five electrical protection systems designed to respond to various operating anomalies. These measures help protect the power supply and connected components against situations such as overloads, voltage fluctuations and short circuits.

OPP: over-power protection.
OCP: overcurrent protection.
OVP: overvoltage protection.
UVP: undervoltage protection.
SCP: short-circuit protection.

ATX form factor and input power
Its Intel ATX 12V form factor and dimensions of 140 x 150 x 86 mm make it easy to install in compatible computer cases. It also supports a wide input voltage range of 100 to 240V AC, making it suitable for different power grids.

Dimensions: 140 x 150 x 86 mm.
COLOR: negro.
Input voltage : 100-240V CA.
Input current: 5-10A.
Input frequency: 47-63Hz.

Safety and conformity certifications
The Einarex Apex L1 650W has various certifications and declarations of conformity relating to electrical safety, electromagnetic compatibility and restrictions on hazardous substances, in accordance with the applicable standards.

CE.
RoHS.
UKCA.
CB.
FCC.
Volume (m ³): 0.0064
