MSI Motherboard for AMD processors X870E-GAMING PLUS-WIFI AM5-ATX 100135716

The MSI X870E GAMING PLUS WIFI is based on the AMD X870E chipset and supports AMD processors for the AM5 socket. It has four DDR5 slots for up to 256 GB of RAM. Other features of the MSI X870E GAMING PLUS WIFI include one PCIe 5.0 x16 slot, one PCIe 4.0 x16 slot (x4 lanes), one PCIe 3.0 x16 slot (x1 lane) and one PCIe 3.0 x1 slot. In addition, the MSI X870E GAMING PLUS WIFI features 8-channel sound, a 2.5 Gigabit LAN interface, WiFi 7, Bluetooth 5.4, four SATA3 ports, three M.2 ports and a range of USB ports.
Type: Base Plate
Socket: AM5
CPU max number x.: 1
Operating System Support: Windows 10 ready, Windows 11 ready
Processor - Supported models: Ryzen 5 7xxx (Raphael), Ryzen 5 7xxxX (Raphael), Ryzen 5 7xxxF (Raphael), Ryzen 5 7xxxX3D (Raphael), Ryzen 5 8xxxF (Phoenix), Ryzen 5 8xxxG (Phoenix), Ryzen 5 9xxx (Granite Ridge), Ryzen 5 9xxxX (Granite Ridge), Ryzen 5 9xxxF (Granite Ridge), Ryzen 7 7xxx (Raphael), Ryzen 7 7xxxX (Raphael), Ryzen 7 7xxxX3D (Raphael), Ryzen 7 8xxxG (Phoenix), Ryzen 7 8xxxF (Phoenix), Ryzen 7 9xxxX (Granite Ridge), Ryzen 7 9xxxX3D (Granite Ridge), Ryzen 9 7xxx (Raphael), Ryzen 9 7xxxX (Raphael), Ryzen 9 7xxxX3D (Raphael), Ryzen 9 9xxxX (Granite Ridge), Ryzen 9 9xxxX3D (Granite Ridge)
Slots - PCIe x 16: 3x (of which: 1x PCIe x 16, 1x PCIe x 4, 1x PCIe x 1)
Form factor: ATX
Usage: PC
Power supply: EPS12v 2.9 x (24 + 2 x 8-pin)
Memory - maximum : 256 GB
Connections (external) - USB 3.1: 2
Internal Connections - SATA: 4
Optional connections - USB 3.0: 4
RGB Standard: Mystic Light
Controller SATA: AMD X870E
Controller USB: AMD X870E
Integrated graphics: The graphics connectors on the motherboard can only be used when a CPU with an integrated graphics chip is used.
Sound: Realtek® ALC897 Codec
LAN: Realtek ® 8126 5G LAN
Dimensions: Width: 243,84 mm x Height: 304,8 mm
