MSI 23.8-inch touchscreen all-in-one computer with Windows 11 Pro MODERN-AM242TP CORE-5-120U 8GB 512GB-SSD DSP0000043228

Features of the MSI Modern AM242TP 1M-1227EU Intel Core 5 120U 8GB 512GB SSD 23.8" Touchscreen Windows 11 Pro
The MSI Modern AM242TP 1M-1227EU is an all-in-one computer designed for professional environments, offices and workspaces looking to combine performance, functionality and space saving. Equipped with an Intel Core 5 120U 10-core processor, 8 GB of DDR5 memory and 512 GB SSD storage, it offers a configuration suitable for productivity tasks, business management and everyday use. Its 23.8-inch Full HD IPS touchscreen, Wi-Fi 6E connectivity and Windows 11 Pro operating system complete a versatile computer with an elegant black finish.
Intel Core 5 120U processor: performance for smooth working
The Series 1 Intel Core 5 120U features a 10-core, 12-thread architecture that combines performance and energy efficiency. Its 2 performance cores and 8 efficiency cores can handle office applications, web browsing, video conferences and multitasking. With a turbo frequency of up to 5 GHz and 12 MB of Intel Smart Cache, it provides responsiveness for the everyday needs of a professional environment.

Processor: Intel Core 5 120U Series 1.
Cores and threads: 10 cores and 12 threads.
Architecture: 2 performance cores and 8 efficiency cores.
Maximum turbo frequency: 5 GHz.
Efficiency core turbo frequency: up to 3.8 GHz.
Base frequencies: 1.4 GHz for performance cores and 0.9 GHz for efficiency cores.
Cache: 12 MB Intel Smart Cache.
Base power: 15 W, with a maximum turbo power of 55 W.
Chipset: Intel SoC.

23.8-inch Full HD IPS touchscreen
The 23.8-inch touchscreen lets you interact directly with applications, documents and professional tools, providing an intuitive user experience. Its IPS panel with a Full HD resolution of 1920 x 1080 pixels delivers a suitable viewing experience for working with spreadsheets, presentations and multimedia content. It also features an anti-glare coating and tilt adjustment to adapt the screen position to the user's needs.

Diagonal: 60.5 cm (23.8 inches).
Resolution: Full HD, 1920 x 1080 pixels.
Technology: IPS touchscreen panel.
Aspect ratio: 16:9.
Brightness: 250 cd/m².
Pixel size: 0.2745 x 0.2745 mm.
SURFACE: antirreflectante.
Adjustable tilt: from -4° to 20°.

8 GB DDR5 memory and NVMe SSD storage of 512 GB
This computer features 8 GB of DDR5 memory at 5600 MHz, a technology that provides the bandwidth required for productivity applications and everyday tasks. It has two SO-DIMM memory slots and supports expansion up to 64 GB, offering room to grow. The M.2 SSD storage with a PCI Express 4.0 interface and NVMe technology helps reduce loading times and provides quick access to files and programs.

Installed RAM: 8 GB DDR5-SDRAM at 5600 MHz.
Configuration: 1 module of 8 GB.
Memory slots : 2 SO-DIMM.
Maximum supported memory : 64 GB.
Memory form factor: DIMM/SO-DIMM.
Storage: 1 SSD drive of 512 GB.
Interface: PCI Express 4.0 with NVMe technology.
SSD form factor: M.2 2280 (22 x 80 mm).

Integrated Intel graphics and sound with built-in speakers
The integrated Intel Graphics adapter can handle the display of office applications, multimedia content and everyday graphics tasks without the need for a dedicated graphics card. The computer also has two built-in speakers and a Realtek ALC256 sound chip, providing an integrated audio solution for meetings, multimedia playback and everyday professional use.

Graphics: integrated Intel Graphics.
GPU manufacturer: Intel.
Dedicated graphics card: not included.
Audio: Realtek chip ALC256.
Speakers: 2 integrated.

2 MP camera and Windows Hello compatibility
Thanks to its integrated 2-megapixel camera, the MSI Modern AM242TP lets you make video calls and take part in virtual meetings without installing an external webcam. It is also compatible with Windows Hello, a Windows feature designed to facilitate sign-in using supported authentication methods.

Camera: integrated 2 MP.
Recommended use: video conferencing, online meetings and professional communication.
Security: Windows Hello compatibility.

Wi-Fi 6E, Bluetooth 5.3 and Ethernet connectivity
The MSI Modern AM242TP offers Wi-Fi 6E wireless connectivity via the Intel Wi-Fi 6E AX211 controller, suitable for high-speed network connections with compatible devices. It also features Bluetooth 5.3 for connecting wireless peripherals and an RJ-45 Ethernet port for accessing wired networks, providing different connection options to suit the needs of the work environment.

Wi-Fi: Wi-Fi 6E (802.11ax).
WLAN controller: Intel Wi-Fi 6E AX211.
Bluetooth: version 5.3.
Ethernet: wired network connection.
LAN port: 1 connector RJ-45.

Extensive USB, HDMI and audio connectivity
The range of connections on the MSI Modern AM242TP 1M-1227EU makes it easy to integrate accessories and peripherals into the workstation. It includes six USB ports across USB 2.0, USB 3.2 Gen 2 Type-A and Type-C connections, as well as two HDMI 2.0 connections. This configuration allows you to connect compatible storage devices, keyboards, mice and audiovisual equipment.

USB 2.0: 2 ports.
USB 3.2 Gen 2 Type-A: 2 ports.
USB 3.2 Gen 2 Type-C: 2 ports.
HDMI: 2 ports HDMI 2.0.
Wired network: 1 port RJ-45.
Audio: microphone connection and combined headphone/microphone jack.

All-in-one design with VESA mount and black finish
Its all-in-one PC form factor integrates the computer’s main components and display into a single structure, helping keep the desk tidier and more organised. The black finish offers a look suited to offices, studies and professional spaces. It also supports VESA mounting (75 x 75 mm) and features a Kensington security slot, making it easy to install using compatible mounts and allowing you to add a physical locking system.

Device type: all-in-one PC.
Orientation: professional and business use.
COLOR: negro.
VESA mounting: 75 x 75 mm.
Physical security: Kensington slot.
Dimensions with stand: 652 x 222 x 455 mm (width x depth x height).
Power adapter : 120 W.

Windows 11 Pro for productivity and business environments
The computer includes Windows 11 Pro preinstalled, an operating system designed for both professional users and organizations that need productivity, management and security tools. Its integration with the MSI Modern AM242TP hardware provides a work environment ready for business applications, administrative tasks and digital collaboration.

Operating system: Windows 11 Pro.
Usage environment: offices, businesses, professional practices and remote work.
Features: Windows 11 Pro productivity, management and security tools.

Other technical specifications
The MSI Modern AM242TP 1M-1227EU also has environmental specifications that define the recommended temperature and humidity ranges for operation and storage, helping ensure proper use of the equipment under the specified conditions.

Operating temperature: from 0°C to 35°C.
Storage temperature: from -20°C to 60°C.
Operating relative humidity: from 0% to 85 %.
Storage relative humidity: from 0% to 90 %.
